AMCI SD17060B

Brand:AMCI

Model number:SD17060B

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AMCI SD17060B Input module




INQUIRE NOW

Products Name: AMCI SD17060B

PRODUCT DESCRIPTION

 SD17060B and SD17060B-03 digital inputs accept 5Vdc to 24Vdc without the need of an external current limiting resistor

 SD17060B-25 digital inputs will work with 24Vdc only

Common features of the three drivers include:

 Inputs that accept 5Vdc to 24Vdc without the need of an external current limiting resistor

 Anti-Resonance Circuitry

 Back-EMF Protection Circuity

 Programmable Idle Current Reduction

 Programmable Current Loop Gain

 Programmable Pulse Train Input (Step/Direction or CW/CCW)

 Programmable Active State for the Disable Input

Description:

 If your year of manufacture is 2009 or later, (digits 3 and 4 are “09” or greater), then this manual

applies.

 If your month and year of manufacture is December of 2008, (digits 1 through 4 are “1208”), and the

sequential number is “0135” or greater, then this manual applies.

 If your month and year of manufacture is December of 2008, (digits 1 through 4 are “1208”), and the

sequential number is less than “0135” then most of the information in this manual applies. The only

difference is that these older SD17060B drivers require external resistors for input signals greater than

5Vdc. Refer to Appendix A on page 18 for additional information.

 If your month and year of manufacture is November of 2008 or earlier, (digits 1 through 4 are “1108”

or less), then most of the information in this manual applies. The only difference is that these older

SD17060B drivers require external resistors for input signals greater than 5Vdc. Refer to Appendix A

on page 18 for additional information.

For SD17060B-03 Drives...

 The “-03” option was added in February of 2010. This manual applies to all SD17060B-03 units.

For SD17060B-25 Drives...

 SD17060B-25 drivers have different resolution settings than the SD17060B and SD17060B-03. In

addition to this change, the SD17060B-25 will only accept 24Vdc input signals. The SD17060B-25

cannot be used in systems that have 5Vdc differential or 12Vdc single ended signals.
