ABB PP835A Overview

The ABB PP835A is a power supply module that is part of ABB's Freelance Distributed Control System (DCS). It provides a reliable power source for controllers and other modules within the Freelance system.

Product Detailed Description

• Function:

• Converts input power to the stable DC voltages required by the Freelance system.

• Supplies power to controllers, I/O modules, and other system components.

• Typically includes overvoltage, overcurrent, and short-circuit protection to safeguard system hardware.

• May offer redundancy options for increased system reliability.

• Features:

• Designed for use with the ABB Freelance DCS system.

• DIN rail mounting.

• Compact design.

• High reliability.

• May support hot-swapping (depending on system configuration).

Product Parameters

As there may be different versions or configurations of the ABB PP835A, the following are some typical parameters for Freelance power supply modules. Always refer to the official datasheet for the specific PP835A model:

• Input Voltage:

• E.g., 24 V DC (typical), with a potentially wider permissible range.

• Output Voltage:

• E.g., 5 V DC, possibly with other output voltages.

• Output Current:

• Varies depending on the specific model, e.g., 3 A, 5 A, etc.

• Power:

• Varies depending on the specific model.

• Mounting Method:

• DIN rail mounting.

• Connection Method:

• Screw terminals.

• Protection Degree:

• Typically IP20.

• Ambient Temperature:

• Operating temperature range may be -20 °C to +70 °C (depending on the specific model).

• Redundancy Support:

• Some configurations may support redundant operation.

• Certifications:

• May include CE, UL, etc. certifications (refer to the specific product manual).

Product Advantages

• Designed for Freelance:

• Fully compatible with the ABB Freelance DCS system, ensuring optimal performance and reliability.

• High Reliability:

• Provides a stable power source for critical control systems.

• Redundancy Options:

• Increases system availability and fault tolerance (if configured with redundancy).

• Easy Installation:

• DIN rail mounting simplifies the installation process.

• Compact Design:

• Saves space in the control cabinet.

Precautions

• Correct Selection:

• Choose the appropriate PP835A model based on the power requirements of the Freelance system, including the necessary voltage and current.

• Correct Installation:

• Follow ABB's installation guidelines, ensuring the module is securely mounted and correctly wired.

• Power Connection:

• Ensure the input power supply voltage is within the permissible range and connect the power and grounding wires correctly.

• Environmental Conditions:

• Ensure the operating environment temperature is within the allowable range and avoid humidity and dust.

• Maintenance:

• While power supply modules typically do not require extensive maintenance, their operating status and connections should be checked regularly.

• Hot-Swapping:

• If the system supports hot-swapping, follow the correct procedures for module replacement.

Product Applications

The ABB PP835A power supply module is primarily used in:

• ABB Freelance Distributed Control System (DCS):

• Powering controllers (e.g., PM864A, PM865) in the Freelance system.

• Powering I/O modules (e.g., S800 I/O) in the Freelance system.

• Powering communication modules and other components in the Freelance system.
