HIMA Z7128/6217/C5/ITI Output module

HIMA Output Modules Overview

HIMA offers a variety of output modules as part of its Safety Integrated Systems (SIS). These modules are used to transmit safety-related signals from the control system's safety logic to field actuators such as valves, relays, and contactors to implement safety functions. HIMA output modules are known for their high reliability and compliance with stringent safety standards.

Product Detailed Description

• Function:

• Receives safety-related signals from the HIMA safety controller.

• Controls connected field actuators based on the received signal status.

• Provides safety-related outputs, ensuring that the system can enter a safe state in the event of a fault.

• Features diagnostic functions to detect its own faults and external wiring faults (e.g., short circuits, open circuits).

• Some modules support hot-swapping for easy maintenance and replacement.

• Features:

• Complies with various safety standards such as IEC 61508 (SIL 3/4), EN 50156, NFPA 85, etc. (depending on the model).

• Offers redundant design options to enhance availability and fault tolerance.

• Available with different output types such as relay outputs, solid-state outputs, current outputs, etc., to suit various actuators.

• Features galvanic isolation to protect the control system from field-side interference.

• Configurable parameters such as fail-safe state.

Product Parameters

As HIMA offers a range of output modules, the following are some general parameters. Always refer to the official datasheet for the specific model:

• Output Type:

• Relay

• Solid State

• Current

• Number of Channels:

• E.g., 4 channels, 8 channels, 16 channels, etc.

• Rated Voltage:

• E.g., 24 V DC, 48 V DC, 115 V AC, 230 V AC (depending on output type).

• Rated Current:

• E.g., 2 A, 5 A (depending on output type and channel).

• Diagnostic Functions:

• Open-circuit detection

• Short-circuit detection

• Overload detection

• Line monitoring

• Safety Integrity Level (SIL):

• SIL 3 or SIL 4 (depending on the model).

• Connection Method:

• Screw terminals

• Pluggable terminals

• Degree of Protection (IP):

• E.g., IP20.

• Operating Temperature:

• E.g., 0 °C to +60 °C (depending on the model).

• Standards Compliance:

• IEC 61508

• EN 50156

• NFPA 85

• And others (depending on the model).

Product Advantages

• High Safety:

• Designed specifically for safety-critical applications, complying with the highest safety standards.

• High Reliability:

• Robust hardware design and comprehensive diagnostic functions ensure reliable operation.

• Fault Tolerance:

• Redundancy options enhance system availability.

• Flexibility:

• Available with various output types and channel counts to suit different application needs.

• Easy Integration:

• Seamless integration with HIMA safety controllers.

• Powerful Diagnostics:

• Quickly detects and reports faults, simplifying maintenance and troubleshooting.

Precautions

• Correct Selection:

• Choose the appropriate output module based on specific safety requirements, actuator type, and load characteristics.

• Correct Installation:

• Follow HIMA's installation guidelines, ensuring the module is securely mounted and correctly wired.

• Safety Circuit Design:

• Integrate the output module into a safety circuit that complies with relevant safety standards.

• Power Requirements:

• Use a power supply that meets the module's specifications.

• Load Characteristics:

• Ensure that the voltage and current requirements of the connected actuators are within the module's ratings.

• Regular Testing:

• Regularly test the safety functions to ensure that the system can reliably enter a safe state when needed.

• Follow Manuals:

• Always follow the relevant HIMA product manuals and safety guidelines.

Product Applications

• Process Industry:

• Oil & Gas

• Chemical

• Pharmaceutical

• Power Generation:

• Power plant safety systems

• Transportation:

• Railway signaling systems

• Burner Management Systems (BMS):

• Boiler safety

• Emergency Shutdown (ESD):

• Protecting personnel and equipment

• Fire and Gas (F&G):

• Actuation of fire and gas detectors
