Brand： Honeywell
Model number：900B16
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.4kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Support for DO channel ganging
The UIO-DO channel is now enhanced to support ganging for enabling the delivery of more
current output to the field (maximum current output of up to 2.0 Amperes). This is accomplished
using the existing UIO hardware. DO channel ganging simply requires software configuration of
up to four adjacent DO channels of the UIO module and appropriate channel wiring accordingly.
ATTENTION
l Up to four DO channels can be ganged at a time.
l UIO-channel 32 cannot be ganged with channel 1.
Support for pulse counting functionality
The UIO module DI channel is capable of providing pulse counting functionality. However, only
four DI channels (channels 15, 16, 17 and 18) support pulse counting functionality.
The UIO-DI channel pulse counting supports counting up to 10 KHz of input pulse frequency.
The UIO DI channel configuration consists of simply setting the Digital Input Type parameter to
“Accum” from the Configuration tab of the DI channel.
- 33 -
ATTENTION
Though UIO supports redundancy, it does not support pulse count synchronization.
Therefore, after a switchover the counters are reset and restart at 0. If pulse count
synchronization is required, you must use the Series C Pulse Input Module.
Features of UHIO
The key features of the UHIO are:
l Supports both redundant and non-redundant configuration for C300 Controller, UIO module,
and CF9.
l Supports interchangeability of Series C components.
l Minimizes the effort for rewiring.
The UHIO also supports the following features.
l Provides mechanical connection to the TDC 2000 cabinet Backplane.
l Supports cabinet ground connections through the IOTA mounting screws.
l Provides electrical-mechanical connection to the IOM.
l Provides electrical-mechanical connection to the redundant IOL cable pair.
l Supports 24V fused electrical connections to the IOM(s) - Series C 24V and COM power supply.
l Supports a signal common ground.
l Supports precision resistors for measuring analog inputs.
The UHIO’s CSA General Purpose certification is applicable within Data Hiway (TDC 2000) cabinets
with the Series C Power supply SPS5792-142935 (HPN 51454517-100). If any modifications have
occurred since first installation, the UHIO’s CSA General Purpose certification is voided and it is
the responsibility of the end user to ensure they are still conforming to all applicable agency rules
and regulations. The original TDC Basic Power Supplies do not support the UHIO CSA General
Purpose Certification.
CE Mark certification
The UHIO's CE Mark is only applicable for installations within Data Hiway (TDC 2000) cabinets with
the Series C Power supply SPS5792-142935 (HPN 51454517-100). It is assumed that the state of
as shipped and as first installed has been maintained for all applicable installations. For
installations that do not satisfy the previously mentioned conditions, the end user is responsible to
ensure that they conform to all applicable agency rules and regulations.
CC-HUIO12
The above constraints also apply to the CC-HUIO12 IOTA. Note that the CC-HUIO12 was tested
with TCB cable 51192054 only. Using the original TCB cable 30731611 with adaptor cable 51202979
may not pass CE Mark tests. For the conducted immunity test between 150kHZ and 250kHz, the AI
accuracy was 4.3% instead of its normal 0.1% at room temperature.
