HONEYWELL R7847C1005 Dynamic Self Check Rectification Amplifier

Product Description

The Honeywell R7847C1005 is a solid-state plug-in amplifier designed to respond to inputs from flame detectors. It is specifically designed for use with 7800 series relay modules and is compatible with Honeywell's

ultraviolet flame sensors (C7012E, F). When used in conjunction with the 7800 series, it provides a reliable flame detection system for various industrial applications.

Key Features and Benefits

• Dynamic Self-Check: Continuously monitors the flame detection system for optimal reliability and safety.



• Flame Failure Response Time: Offers both 2-second and 3-second flame failure response times to accommodate different application requirements.

• Versatile Compatibility: Works seamlessly with 7800 series relay modules and Honeywell's ultraviolet flame sensors.



• Easy Installation: Plug-in design simplifies installation and integration into existing systems.

• Flame Signal Strength: Provides a flame signal strength range of 0.0 to 5.0 Vdc for precise monitoring.



• Color-Coded Labels: Clear identification of flame detection type for easy maintenance and troubleshooting.



• Safety Shutdown: In the event of a flame detection system failure, the 7800 series relay module will lock out for added safety.

Technical Specifications

• Type: Rectification Flame Amplifier



• Flame Failure Response Time: 2.0 seconds or 3.0 seconds

• Self Checking: Dynamic Self-Check

• Use With Primary Safety Control: 7800 SERIES Relay Modules



• Use With Flame Sensor: Gas, oil, coal: Ultraviolet Flame Sensor C7012E, F



• Flame Signal Strength: 0.0-5.0 Vdc



Precautions

• Compatibility: Ensure compatibility with other components in your system, including the 7800 series relay modules and flame sensors.

• Installation: Follow the manufacturer's installation instructions carefully to ensure proper operation and safety.

• Maintenance: Regular inspection and maintenance are essential to maintain optimal performance.

• Environment: Consider the environmental conditions of the application, such as temperature and humidity, when selecting and installing the amplifier.

Applications

The Honeywell R7847C1005 is widely used in various industries where flame detection is critical, including:

• Boilers: Ensuring safe and efficient combustion.

• Furnaces: Monitoring flame presence for optimal heating.

• Burners: Protecting equipment and personnel from flame failures.

• Industrial Processes: Monitoring combustion processes in various industrial applications.

For more detailed information, please refer to the product datasheet or contact Honeywell directly.

Note: This is a general overview of the Honeywell R7847C1005. Specific applications and requirements may vary. It is always recommended to consult with a qualified professional for advice on selecting and using this

product.
