Honeywell 05701-A-0284 Pressure transmitter

Honeywell 05701-A-0284 Overview

The Honeywell 05701-A-0284 is a process pressure transmitter belonging to Honeywell's SmartLine® family of pressure transmitters. These transmitters are designed to provide high-accuracy and reliable pressure measurements in a wide range of industrial applications. The specific suffix in the model number indicates particular configurations and features.

Product Detailed Description

• Function:

• Accurately measures process pressure (gauge, absolute, or differential).

• Converts the measured pressure value into a standard 4-20 mA HART® protocol output signal for communication with control systems, recorders, or other monitoring devices.

• Features digital communication capabilities, allowing for remote configuration, calibration, and diagnostics.

• Offers a variety of ranges and accuracy options to meet diverse application needs.

• Rugged and durable design suitable for harsh industrial environments.

• Features:

• High accuracy and long-term stability.

• Employs SmartLine® technology for enhanced performance and reliability.

• Supports HART® communication protocol.

• Configurable via local buttons and display (if equipped).

• Available with various process connections and diaphragm materials to suit different media.

• Features overpressure protection.

Product Parameters

As the specific model suffix (e.g., 05701-A-0284) indicates particular configurations, the following are some typical parameters for Honeywell SmartLine® pressure transmitters. Always refer to the official datasheet for the specific model for accurate parameters:

• Measurement Type:

• Gauge Pressure

• Absolute Pressure

• Differential Pressure

• Pressure Range:

• Wide range of options available, e.g., 0-10 kPa, 0-10 MPa, etc. (depending on the specific model).

• Output Signal:

• 4-20 mA HART®

• Accuracy:

• Typically ±0.065% of full scale or better (depending on the specific model).

• Supply Voltage:

• Typically 24 V DC (loop-powered).

• Operating Temperature:

• Typically -40 °C to +85 °C or a similar range (depending on the specific model).

• Protection Degree:

• Common protection ratings include IP66/IP67 or higher (depending on the specific model).

• Process Connection:

• Various threaded connections (e.g., 1/2" NPT, 1/4" NPT) or flanged connections (depending on the specific model).

• Diaphragm Material:

• Stainless Steel (316L SS), Hastelloy C-276, etc. (depending on the specific model to suit different media).

Product Advantages

• High Accuracy and Reliability:

• Provides accurate and stable pressure measurements, ensuring the precision of process control.

• SmartLine® Technology:

• Offers enhanced performance, diagnostics capabilities, and long-term stability.

• HART® Communication:

• Supports digital communication for easy remote configuration, calibration, and diagnostics, reducing maintenance costs.

• Wide Range of Configurations:

• Suitable models can be selected based on different measurement types, pressure ranges, and process connections.

• Rugged and Durable:

• Designed to withstand harsh industrial environments, offering a long service life.

• Easy Installation and Maintenance:

• Various mounting options and HART® communication simplify the installation and maintenance process.

• Global Brand and Support:

• Honeywell is a globally recognized industrial automation brand, providing comprehensive technical support and after-sales service.

Precautions

• Correct Selection:

• Choose the appropriate model based on the specific pressure range, media compatibility, accuracy requirements, process connection, and output signal type.

• Correct Installation:

• Follow Honeywell's installation guidelines, ensuring the transmitter is securely mounted and the pressure port is correctly connected without leaks.

• Media Compatibility:

• Ensure the transmitter's diaphragm and other wetted materials are compatible with the media being measured to prevent corrosion or damage.

• Electrical Connection:

• Connect the power and signal wires correctly according to the wiring diagram, ensuring proper grounding.

• Calibration:

• Regular calibration of the transmitter may be necessary depending on the application requirements to ensure measurement accuracy. It is recommended to use standard calibration equipment and procedures.

• Environmental Conditions:

• Avoid using the transmitter in environments exceeding its operating temperature and humidity ranges.

• Avoid strong mechanical shocks and vibrations.

• HART® Communication:

• If HART® communication functionality is required, ensure that the control system or handheld terminal supports the HART® protocol.

Product Applications

Honeywell 05701-A-0284 or similar SmartLine® pressure transmitters are widely used in various industrial sectors, including but not limited to:

• Industrial Automation:

• Pressure monitoring and control in process control systems.

• Level measurement (using differential pressure transmitters).

• Flow measurement (using differential pressure transmitters and differential pressure flow meters).

• Oil and Gas:

• Wellhead pressure monitoring.

• Pipeline pressure monitoring and control.

• Tank pressure monitoring.

• Chemical:

• Reactor pressure control.

• Column pressure monitoring.

• Power Generation:

• Boiler pressure monitoring.

• Steam pressure measurement.

• Water and Wastewater Treatment:

• Water pressure monitoring and control.

• Pump control.

• Food and Beverage:

• Process pressure monitoring and control.

• Pharmaceutical:

• Pressure monitoring in critical processes.

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
