Honeywell 05701-A-0361 Engineering Card

Product Description

The Honeywell 05701-A-0361 is an Engineering Card designed for use with Honeywell's System 57 gas detection systems. This card provides a common interface for commissioning, configuration, and operation of the various control cards within the System 57. It is an essential component for installing, maintaining, and troubleshooting the gas detection system.

Key Features and Specifications

• Purpose: Provides a user-friendly interface for system configuration and operation.



• Compatibility: Specifically designed for Honeywell System 57 gas detection systems.



• Power: Requires 18-32 VDC, 1.5W power supply.



• Dimensions: 13.2 cm x 2.5 cm x 17 cm

• Functions:

• Commissioning of control cards



• Configuration of system parameters

• Monitoring system status

• Fault diagnosis and troubleshooting

Advantages

• Ease of Use: Simplifies the configuration and operation of the System 57.

• Versatility: Compatible with a wide range of control cards.

• Reliability: Built to Honeywell's high quality standards for industrial applications.

Precautions

• Compatibility: Ensure compatibility with the specific System 57 configuration.

• Power: Connect to a suitable power supply.

• Environment: Avoid exposure to extreme temperatures and humidity.

• Maintenance: Follow Honeywell's recommended maintenance procedures.

Applications

• Gas Detection Systems: Used in various industries where gas detection is critical, such as:

• Oil and gas

• Chemical processing

• Wastewater treatment

• Food and beverage

• Safety Systems: Provides a reliable interface for monitoring and controlling safety systems.

Additional Notes

• System 57: The System 57 is a comprehensive gas detection system that offers a wide range of sensors and control options.



• Configuration: The Engineering Card allows users to configure various parameters, including alarm levels, calibration data, and communication settings.

• Troubleshooting: The card can be used to diagnose faults and troubleshoot issues within the system.
