Honeywell CC-TAIX01 Analog Input Modules

Brand: Honeywell

Model number:CC-TAIX01

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.5kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Honeywell CC-TAIX01 Analog Input Modules

INQUIRE NOW

Products Name: Honeywell CC-TAIX01 Analog Input Modules

PRODUCT DESCRIPTION

Honeywell CC-TAIX01 Overview

The Honeywell CC-TAIX01 is an Analog Input module belonging to the AIO (Analog Input/Output) series within Honeywell Process Solutions. It is typically used in Honeywell's Experion PKS Distributed Control System (DCS) to receive analog signals from field instruments.

Product Detailed Description

  • Function:

    • Receives analog current or voltage signals from field transmitters and other instruments.

    • Converts these analog signals into digital signals for processing and control by the Experion PKS system.

    • Provides channel isolation to enhance system reliability and noise immunity.

    • Supports various input types and range configurations.

    • Features onboard diagnostics for detecting faults in the module and channels.

  • Features:

    • 8 analog input channels.

    • Configurable to receive different input types (e.g., 4-20 mA, 1-5 V DC, 0-10 V DC).

    • Channel-to-channel isolation.

    • High-resolution Analog-to-Digital Converter (ADC).

    • Cold junction compensation (for thermocouple inputs, if supported).

    • Line break detection.

    • Online Replacement capability.

    • Communicates with the Experion PKS controller via the system bus.

Product Parameters

Please note that specific parameters may vary slightly depending on the version or configuration of the CC-TAIX01. The following are some typical parameters:

  • Number of Input Channels:

    • 8

  • Input Types (Configurable):

    • Current: 4-20 mA

    • Voltage: 1-5 V DC, 0-5 V DC, 0-10 V DC

  • Input Impedance:

    • Current Input: Typically 250 Ω

    • Voltage Input: Typically > 1 MΩ

  • Resolution:

    • Typically 16 bits or higher

  • Accuracy:

    • Typically ±0.1% or better (depending on range and conditions)

  • Channel Isolation:

    • Isolation between channels and between channels and the system bus

  • Supply Voltage:

    • Typically provided through the Experion PKS system backplane

  • Power Consumption:

    • Refer to the product manual for specific values

  • Operating Temperature:

    • Typically -40 °C to +70 °C (depending on the model)

  • Storage Temperature:

    • Typically -40 °C to +85 °C (depending on the model)

  • Relative Humidity:

    • 5% to 95% non-condensing

  • Standards Compliance:

    • CE, UL, CSA, etc. (refer to the specific product manual)

Product Advantages

  • Integration with Experion PKS:

    • Specifically designed for seamless integration and optimized performance with the Experion PKS system.

  • High Accuracy and Reliability:

    • Provides accurate and reliable acquisition of analog signals.

  • Channel Isolation:

    • Enhances system noise immunity and reliability.

  • Flexible Input Configuration:

    • Each channel can be independently configured for different input types and ranges, accommodating various field instruments.

  • Online Replacement:

    • Supports online replacement, reducing system maintenance downtime.

  • Onboard Diagnostics:

    • Facilitates fault detection and troubleshooting.

  • Wide Operating Temperature Range:

    • Suitable for various industrial environments.

Precautions

  • Correct Installation:

    • Follow Honeywell's installation manual to ensure the module is correctly installed in the Experion PKS cabinet.

  • Correct Wiring:

    • Connect field instrument signal wires according to the wiring diagram, paying attention to polarity and shielding.

  • Grounding:

    • Ensure proper grounding of the module and system to minimize noise interference.

  • Environmental Conditions:

    • Ensure the operating environment temperature and humidity are within the module's allowable range.

  • Electrostatic Discharge (ESD):

    • Take appropriate ESD precautions when handling the module.

  • Configuration:

    • Use the Experion PKS system configuration tools to correctly configure the module's input types and ranges.

  • Maintenance:

    • Regularly inspect the module's connections and status.

Product Applications

The Honeywell CC-TAIX01 Analog Input module is primarily used in various industrial process control applications as part of the Experion PKS system for acquiring analog signals from field instruments, such as:

  • Temperature Measurement:

    • Receiving signals from thermocouples, Resistance Temperature Detectors (RTDs), and temperature transmitters.

  • Pressure Measurement:

    • Receiving signals from pressure transmitters.

  • Flow Measurement:

    • Receiving signals from flow meters.

  • Level Measurement:

    • Receiving signals from level transmitters.

  • Valve Position Feedback:

    • Receiving analog feedback signals from valve positioners.

  • Other Process Variable Measurements:

    • Receiving signals from transmitters for pH, conductivity, etc.
