Honeywell S464G1007 Safety Controller

Honeywell S464G1007 Overview

The Honeywell S464G1007 is a single flame burner safeguard controller designed for automatic starting and monitoring of industrial and commercial burners. It provides the necessary timing and safety functions to ensure efficient and safe combustion processes.

Product Detailed Description

• Function:

• Controls the burner start-up sequence, including prepurge, ignition trial, and flame establishment.

• Continuously monitors the flame status and provides a safety shutdown upon flame failure.

• Provides fixed safety timing to ensure critical operations are completed within safe timeframes.

• Features lockout and non-lockout fault modes.

• Integrated flame detection circuitry compatible with various flame sensors.

• Features:

• Compact design.

• Solid-state electronics for enhanced reliability.

• Clear fault indication.

• Selectable prepurge and ignition timing.

• Compatible with various flame sensors (e.g., flame rod, UV scanner).

Product Parameters

As the S464G1007 is a specific model, the following parameters are based on typical specifications for this model:

• Model: S464G1007

• Application: Single Flame Burner Control

• Power Supply: 120 Vac

• Frequency: 50/60 Hz

• Prepurge Time: Selectable (e.g., 7 seconds, 10 seconds)

• Trial for Ignition Time: Fixed (e.g., 4 seconds)

• Safety Shutdown Time: Fixed (e.g., 3 seconds)

• Flame Detection Input: Suitable for flame rod or UV scanner

• Contact Ratings: Dependent on specific relay outputs

• Ambient Temperature: -40 °F to +140 °F (-40 °C to +60 °C)

• Humidity: 95% RH, non-condensing

• Mounting: Surface mounting

• Wiring: Screw terminals

Product Advantages

• Safety: Provides critical safety timing and flame monitoring to ensure safe burner operation.

• Reliability: Solid-state electronics enhance the controller's reliability and lifespan.

• Easy Installation and Wiring: Compact design and screw terminals simplify installation and wiring.

• Fault Indication: Clear fault indication aids in quick diagnosis and troubleshooting.

• Flexibility: Compatible with various flame sensors, making it suitable for different applications.

Precautions

• Correct Model Selection: Ensure the selected model matches the specific burner type, fuel, and safety requirements.

• Proper Installation and Wiring: Install and wire according to Honeywell's installation instructions and local electrical codes.

• Flame Sensor Compatibility: Ensure the flame sensor used is compatible with the S464G1007 controller.

• Safety Checks and Testing: Perform safety checks and functional tests before burner start-up and on a regular basis to ensure proper operation of the controller and the entire burner safety system.

• Follow Manufacturer Guidelines: Always adhere to the installation, operation, and maintenance guidelines provided by Honeywell.

Product Applications

• Commercial Burners: Used in commercial boilers, water heaters, and air heaters.

• Industrial Burners: Used in industrial process heating applications.

• Oil and Gas Burners: Suitable for burners using various fuels.

• Small to Medium-Sized Burners: Controls burners within its capacity range.
