Honeywell SSCEB31D Miniature Enclosed Limit Switches

Product Description

The Honeywell SSCEB31D is a miniature enclosed limit switch designed for rugged industrial applications. It features a cross roller plunger actuator and is housed in a die-cast zinc alloy case for durability and corrosion resistance. This limit switch is commonly used to detect the position of mechanical components in automation systems.

Key Features and Specifications

• Actuator: Cross roller plunger (90° rotated plunger)

• Contacts: SPDT (1 normally open and 1 normally closed)

• Ampere Rating: 5A (thermal)

• Voltage: 240 VAC max

• Housing: Die-cast zinc alloy

• Sealing: IP68

• Approvals: UL, CSA

Advantages

• Rugged Construction: Designed for harsh environments, providing excellent durability and reliability.

• Compact Size: Ideal for applications with limited space.

• Flexible Mounting: Can be mounted in various positions.

• Variety of Actuators: Available with different actuator types to suit different applications.

• IP68 Rating: Ensures protection against dust and water ingress.

Precautions

• Installation: Ensure proper mounting and alignment of the actuator to prevent damage.

• Wiring: Connect the limit switch according to the wiring diagram and applicable electrical codes.

• Environment: Avoid exposing the limit switch to excessive vibration or corrosive substances.

• Overload Protection: Do not exceed the rated electrical parameters.

• Maintenance: Periodic inspection and cleaning are recommended.

Applications

The SSCEB31D is widely used in various industrial applications, including:

• Machine Automation: Detecting the position of machine components such as slides, cams, and limit switches.

• Conveyor Systems: Monitoring the position of conveyors and detecting product presence.

• Packaging Machinery: Controlling the movement of packaging materials and products.

• Material Handling: Detecting the position of lifting devices and gates.

Additional Information

• Data Sheet: For more detailed specifications and technical information, refer to the official Honeywell product data sheet.

• Accessories: A variety of accessories are available to customize the limit switch for specific applications.

• Replacement: When replacing the limit switch, ensure that the replacement has the same specifications and ratings.

For more detailed information and specific product recommendations, please refer to the Honeywell product catalog or consult with a Honeywell authorized distributor.
