MVI56-S3964R ProSoft

The MVI56-S3964R module requires the following minimum hardware and software components:

ƒRockwell Automation ControlLogix™ processor, with compatible power

supply and one free slot in the rack, for the MVI56-S3964R module. The

module requires 800mA of available power.

ƒRockwell Automation RSLogix 5000 programming software version 2.51 or

higher.

ƒRockwell Automation RSLinx communication software

ƒPentium® II 450 MHz minimum. Pentium III 733 MHz (or better)

recommended

ƒSupported operating systems:

o Microsoft Windows XP Professional with Service Pack 1 or 2

o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3

o Microsoft Windows Server 2003

ƒ128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended

1 Set the PRT 2 (for application port 1) and PRT 3 (for application port 2)

jumpers for RS232, RS422 or RS485 to match the wiring needed for your

application. The default jumper setting for both application ports is RS-232.

2 The Setup Jumper acts as "write protection" for the module's flash memory.

In "write protected" mode, the Setup pins are not connected, and the

module's firmware cannot be overwritten. Do not jumper the Setup pins

together unless you are directed to do so by ProSoft Technical Support.

1.5 Install the Module in the Rack

If you have not already installed and configured your ControlLogix processor and

power supply, please do so before installing the MVI56-S3964R module. Refer to

your Rockwell Automation product documentation for installation instructions.

Warning: You must follow all safety instructions when installing this or any other electronic

devices. Failure to follow safety procedures could result in damage to hardware or data, or even

serious injury or death to personnel. Refer to the documentation for each device you plan to

connect to verify that suitable safety procedures are in place before installing or servicing the

device.
