ProSoft MVI69-MBTCP module

ProSoft Technology MVI69-MBTCP Overview

The ProSoft Technology MVI69-MBTCP module is an in-rack, single-slot interface module for Rockwell Automation CompactLogix and MicroLogix 1100/1400 processors. It provides a powerful and flexible interface for connecting these controllers to Modbus TCP/IP Ethernet networks. This allows the Rockwell PLCs to act as either a Modbus TCP/IP client (master) or server (slave), enabling seamless data exchange with other Modbus TCP/IP devices.

Product Detailed Description

• Function:

• Enables Rockwell Automation CompactLogix and MicroLogix 1100/1400 processors to communicate with Modbus TCP/IP Ethernet networks.

• Supports both Modbus TCP/IP client (master) and server (slave) functionality simultaneously.

• Allows the Rockwell PLC to read and write data to/from other Modbus TCP/IP devices.

• Facilitates integration with a wide range of Modbus TCP/IP compatible devices such as HMIs, SCADA systems, other PLCs, and various field devices.

• Provides high-speed data transfer over Ethernet.

• Offers configuration and diagnostics through the Rockwell programming environment (RSLogix 5000 or Studio 5000 for CompactLogix, RSLogix 500 for MicroLogix).

• Supports up to 30 Modbus TCP/IP client connections and an unlimited number of server connections.

• Features a built-in Ethernet port for direct connection to the network.

Product Parameters

• Processor Compatibility:

• Rockwell Automation CompactLogix (all series)

• Rockwell Automation MicroLogix 1100

• Rockwell Automation MicroLogix 1400

• Interface:

• Single-slot in-rack module for the CompactLogix/MicroLogix backplane.

• 1 x 10/100Base-T Ethernet port (RJ45 connector).

• Protocols Supported:

• Modbus TCP/IP Client (Master)

• Modbus TCP/IP Server (Slave)

• Client Connections:

• Up to 30 simultaneous client connections.

• Server Connections:

• Unlimited server connections.

• Data Handling:

• Supports Modbus function codes 01, 02, 03, 04, 05, 06, 15, 16, 22, and 23.

• Configurable data mapping between Modbus registers and PLC tags.

• Configuration:

• Integrated into the Rockwell programming environment (RSLogix 5000/Studio 5000 or RSLogix 500).

• No separate programming software required.

• Diagnostics:

• Comprehensive diagnostics available within the Rockwell programming environment.

• LED indicators for module status and network activity.

• Power Requirements:

• Drawn from the CompactLogix/MicroLogix backplane. Refer to the module's datasheet for specific current draw.

• Operating Temperature:

• Typically -25°C to +70°C (refer to the module's datasheet for the exact range).

• Storage Temperature:

• Typically -40°C to +85°C (refer to the module's datasheet for the exact range).

• Humidity:

• 5% to 95% non-condensing.

• Dimensions:

• Standard CompactLogix/MicroLogix single-slot module dimensions. Refer to the module's datasheet for specific dimensions.

• Weight:

• Refer to the module's datasheet for specific weight.

• Certifications:

• UL, cUL, CE (refer to the module's datasheet for a complete list).

Product Advantages

• Seamless Integration:

• Fully integrated into the Rockwell Automation programming environment, simplifying configuration and reducing development time.

• High Performance:

• Provides fast and reliable data transfer over Ethernet.

• Versatile Functionality:

• Supports both Modbus TCP/IP client and server modes simultaneously, offering flexibility in system design.

• Scalability:

• Supports a significant number of client connections and unlimited server connections, accommodating various network sizes.

• Cost-Effective:

• Eliminates the need for external communication gateways or converters, reducing system complexity and cost.

• Robust and Reliable:

• Designed for industrial environments, ensuring reliable operation.

• Comprehensive Diagnostics:

• Easy troubleshooting through integrated diagnostics within the Rockwell software.

Precautions

• Correct Installation:

• Install the module in the designated slot of the CompactLogix/MicroLogix chassis according to the ProSoft and Rockwell documentation.

• Power Requirements:

• Ensure that the CompactLogix/MicroLogix backplane has sufficient power to supply the module.

• Network Configuration:

• Properly configure the IP address and other network settings of the module.

• Ensure that the Modbus TCP/IP devices on the network are configured correctly.

• Wiring:

• Use appropriate Ethernet cables for connecting the module to the network.

• Software Configuration:

• Carefully configure the data mapping between Modbus registers and PLC tags within the Rockwell programming environment.

• Firmware Updates:

• Keep the module firmware updated to the latest version for optimal performance and security. Refer to ProSoft's website for firmware updates and instructions.

• ESD Protection:

• Follow proper electrostatic discharge (ESD) prevention procedures when handling the module.

Product Applications

The ProSoft Technology MVI69-MBTCP module is used in a wide range of industrial automation applications where Rockwell Automation CompactLogix or MicroLogix 1100/1400 PLCs need to communicate with Modbus TCP/IP devices, including:

• HMI Integration:

• Connecting Rockwell PLCs to Modbus TCP/IP based Human Machine Interfaces (HMIs) for visualization and control.

• SCADA Systems:

• Integrating Rockwell PLCs with Supervisory Control and Data Acquisition (SCADA) systems that use Modbus TCP/IP.

• PLC-to-PLC Communication:

• Enabling data exchange between Rockwell PLCs and other PLCs that support Modbus TCP/IP.

• Building Automation:

• Interfacing with Modbus TCP/IP devices used in building management systems such as HVAC controllers, lighting systems, and energy management systems.

• Power and Utilities:

• Connecting to Modbus TCP/IP compliant devices in power generation, transmission, and distribution applications.

• Oil and Gas:

• Integrating with Modbus TCP/IP instruments and control systems in oil and gas facilities.

• Manufacturing:

• Connecting to various Modbus TCP/IP enabled devices such as drives, sensors, and actuators on the factory floor.

• Water and Wastewater Treatment:

• Interfacing with Modbus TCP/IP devices used in water and wastewater treatment plants.
