6AV2144-8JC10-0AA0 Siemens Operation panel

Siemens 6AV2144-8JC10-0AA0 Overview

The Siemens 6AV2144-8JC10-0AA0 is a SIMATIC HMI TP1200 Comfort Panel, belonging to the Siemens SIMATIC Human Machine Interface (HMI) Comfort Panel series. These panels are designed to provide high-performance visualization and operation interfaces for industrial automation applications.

Product Detailed Description

• Function:

• Serves as an operator interface for industrial control systems, used for visualizing process data, controlling machines and equipment, and diagnosing system status.

• Supports touch operation, providing intuitive user interaction.

• Features powerful processing capabilities and memory to handle complex applications.

• Supports PROFINET and other industrial Ethernet protocols for easy integration into automation networks.

• Offers a rich set of visualization elements and functions for creating user-friendly interfaces.

• Features:

• 12-inch widescreen TFT display with a resolution of 1280 x 800 pixels.

• Multi-touch operation.

• High-performance processor.

• Large user memory.

• Integrated PROFINET interface.

• IP65 protection rating (front) suitable for industrial environments.

• Configurable buttons (on some models).

Product Parameters

• Product Name: SIMATIC HMI TP1200 Comfort

• Order Number: 6AV2144-8JC10-0AA0

• Display:

• Size: 12 inch

• Type: TFT Color

• Resolution: 1280 x 800 pixels (widescreen)

• Backlighting: LED

• Brightness: Typ. 300 cd/m²

• Viewing Angle: Wide viewing angle, both horizontal and vertical

• Touchscreen:

• Type: Analog-resistive touchscreen

• Operation: Multi-touch

• Processor:

• High-performance CPU

• Memory:

• User Memory: 12 MB

• For recipe data, archives, etc.

• Interfaces:

• PROFINET: 1 x RJ45

• USB: 2 x USB 2.0 (Type A)

• Ethernet: Supports TCP/IP

• Power Supply:

• 24 V DC (20.4 ... 28.8 V DC)

• Power Consumption:

• Typ. 17 W

• Protection Rating:

• Front panel: IP65

• Rear panel: IP20

• Mounting Type:

• Panel mounting

• Ambient Temperature:

• Operating temperature: 0 °C to +50 °C

• Storage temperature: -20 °C to +60 °C

• Dimensions (W x H x D):

• 336 mm x 252 mm x 63 mm (refer to the manual for panel cutout dimensions)

• Weight:

• Approx. 2.3 kg

• Software:

• Configurable with SIMATIC WinCC Comfort

Product Advantages

• High Performance:

• Powerful processor and sufficient memory for smooth operation of complex HMI applications.

• Clear Visualization:

• High-resolution widescreen display provides clear and vivid images.

• Intuitive Operation:

• Multi-touch functionality offers a convenient user interaction experience.

• Good Connectivity:

• Integrated PROFINET interface for easy connection to Siemens PLCs and other PROFINET devices.

• Multiple USB ports for connecting external peripherals.

• Robust and Durable:

• IP65 protection rating on the front panel suitable for industrial environments.

• Easy Configuration:

• Flexible interface design and function configuration through the powerful SIMATIC WinCC Comfort configuration software.

Precautions

• Correct Installation:

• Follow Siemens' installation guidelines to ensure the panel is securely mounted and correctly connected.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the allowed range.

• Avoid strong vibrations and shocks.

• Software Compatibility:

• Use a compatible version of SIMATIC WinCC Comfort software for configuration.

• Grounding:

• Ensure the panel is properly grounded to prevent electromagnetic interference and ensure safety.

Product Applications

• Industrial Automation:

• Local operation and monitoring of machines and equipment.

• Visualization and control of production lines.

• Human-machine interface for process control systems.

• Building Automation:

• Monitoring and management of HVAC, lighting, and other systems.

• Transportation:

• Traffic control systems, information display systems.

• Other Industrial Fields:

• Any automation application requiring operator visualization and control.
