6AV3688-4EY07-0AA0 SIEMENS Central control module

Siemens SIMATIC OP277 6" Touch Overview

The Siemens SIMATIC OP277 6" Touch (Order No. 6AV3688-4EY07-0AA0) is an Operator Panel with a 5.7-inch TFT color touchscreen, primarily used for operation and monitoring of machines and small systems.

Product Detailed Description

• Function:

• Visualization of machine and process states.

• Allows operators to operate and input data via the touchscreen.

• Communicates with PLCs (Programmable Logic Controllers) via the MPI/PROFIBUS DP interface.

• Supports screen displays, alarm indications, numerical input/output, and simple trend displays.

• Features a compact design suitable for space-constrained applications.

• Offers a certain degree of protection for use in industrial environments.

• Features:

• 5.7-inch TFT color touchscreen with a resolution of 320 x 240 pixels.

• LED backlight.

• MPI/PROFIBUS DP interface.

• RS-232 interface.

• Touchscreen operation.

• Integrated ProTool engineering software (license required).

• Compact dimensions and light weight for easy installation.

Product Parameters

• Display:

• Size: 5.7 inches

• Type: TFT Color

• Touchscreen: Analog-resistive

• Resolution: 320 x 240 pixels (QVGA)

• Backlight: LED

• Number of Colors: 256

• Power Supply:

• Rated Voltage: 24 V DC

• Permissible Range: 20.4 V DC to 28.8 V DC

• Power Consumption: Typ. 8 W

• Interfaces:

• MPI/PROFIBUS DP: 1 x 9-pin D-sub connector

• RS-232: 1 x 9-pin D-sub connector

• Memory:

• User-available memory: Approx. 2 MB (for project data)

• Degree of Protection:

• Front: IP65

• Rear: IP20

• Ambient Temperature:

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: -20 °C to +60 °C

• Dimensions (W x H x D):

• 172 mm x 144 mm x 44 mm

• Installation Cutout Dimensions (W x H):

• 165 mm x 137 mm

• Weight:

• Approx. 0.6 kg

• Engineering Software:

• SIMATIC ProTool (license required)

Product Advantages

• Compact Design:

• Saves installation space, suitable for small machines and systems.

• Color Touchscreen:

• Provides clear and easy-to-read visualization and intuitive operation.

• Reliable Communication:

• Reliable communication with Siemens PLC systems via the MPI/PROFIBUS DP interface.

• Cost-Effective:

• Offers a cost-effective HMI solution for smaller applications.

• Easy Engineering:

• Convenient configuration using SIMATIC ProTool software.

• Robust and Durable:

• IP65 front protection rating, suitable for industrial environments.

Precautions

• Correct Installation:

• Follow Siemens' installation guidelines, ensuring the panel is securely mounted and properly grounded.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Engineering Software:

• Requires licensed SIMATIC ProTool engineering software for project creation and configuration. Note that ProTool is an older software and may have been superseded by newer software like TIA Portal, depending on your system environment.

• Communication Interface:

• Primarily communicates via MPI/PROFIBUS DP; ensure your PLC system supports these interfaces.

• ESD Protection:

• Observe electrostatic discharge (ESD) precautions when handling the HMI panel.

Product Applications

• Small Machine Control:

• Used for controlling and monitoring small production machines.

• Packaging Machinery:

• Operator interface for simple packaging equipment.

• Material Handling Systems:

• For controlling simple conveyors, etc.

• Process Control:

• Monitoring of small process equipment.

• Building Automation:

• For simple HVAC or lighting control systems.
