SIEMENS 3RU2116-0JC1 Central control module

SIEMENS 3-pole contactor Overview

Siemens offers a comprehensive range of 3-pole contactors, which are electromechanical switching devices designed for switching resistive, inductive, and capacitive loads in various industrial and commercial applications. These contactors are primarily used for controlling three-phase electric motors, but can also be used for other three-phase loads like heating elements or lighting.

Product Detailed Description

• Function:

• To make and break three-phase electrical circuits.

• To control the starting and stopping of three-phase electric motors.

• To switch other three-phase loads in automation systems.

• They are typically operated by an electromagnetic coil, which, when energized, closes the main contacts to establish the circuit.

• Features:

• Modular Design: Many Siemens contactor series (e.g., SIRIUS) feature a modular design, allowing for easy assembly of auxiliary contacts, surge suppressors, and other accessories.

• High Switching Capability: Designed to handle significant switching currents and frequent operations.

• Robust Construction: Built to withstand harsh industrial environments, ensuring long service life.

• Various Coil Voltages: Available with a wide range of AC and DC coil voltages to suit different control circuit requirements.

• Finger-safe Terminals: Many models offer finger-safe terminals for enhanced safety during installation and maintenance.

• Wide Temperature Range: Designed for reliable operation across a broad ambient temperature range.

• Compliance with Standards: Manufactured to meet relevant international standards like IEC, UL, CSA.

Product Parameters

Given the wide variety of Siemens 3-pole contactors, specific parameters will vary significantly by series and individual model. Here are some typical parameters you might find:

• Rated Operating Current (Ie): From fractional amperes up to several hundred amperes (e.g., 9 A, 18.5 A, 37 A, 100 A, etc., for AC-3 utilization category).

• Rated Operating Voltage (Ue): Up to 690 V AC or 1000 V AC.

• Rated Insulation Voltage (Ui): Typically higher than rated operating voltage, e.g., 690 V, 1000 V.

• Coil Voltage (Us): Wide range of AC (e.g., 24 V, 110 V, 230 V, 400 V) and DC (e.g., 24 V, 48 V, 110 V, 220 V) options.

• Number of Poles: 3 main poles.

• Auxiliary Contacts: Often includes integrated auxiliary contacts (e.g., 1 NO + 1 NC) and options for adding more.

• Mechanical Life: Typically millions of operating cycles (e.g., 10 million cycles for smaller contactors).

• Electrical Life: Varies significantly based on load and switching frequency (e.g., 1 million cycles for AC-3 at rated current).

• Mounting: DIN rail mountable, screw mounting.

• Degree of Protection (IP): Typically IP20 for terminals, higher for enclosed versions.

• Ambient Temperature: Operating range usually from -25 °C to +60 °C or +70 °C.

• Standards: IEC 60947, UL, CSA, CCC, CE.

Product Advantages

• High Reliability and Durability: Siemens contactors are known for their robust construction and long operational life, even under demanding industrial conditions.

• Space-Saving Design: Many series feature compact dimensions, optimizing space utilization in control cabinets.

• Easy Integration: Modular accessories and common design principles make them easy to integrate into existing systems and panel layouts.

• Versatile Applications: Suitable for a broad range of loads, from motor control to resistive heating and lighting applications.

• Global Compliance: Conforms to major international standards, facilitating use in various markets worldwide.

• Safety Features: Designed with safety in mind, including finger-safe terminals and options for integrated safety functions.

• Comprehensive Range: Siemens offers a vast portfolio, allowing users to find the exact contactor for their specific needs.

Precautions

• Correct Selection: Always select a contactor with ratings (current, voltage, utilization category) appropriate for the specific motor or load it will control. Consider starting currents for motors.

• Proper Wiring: Ensure all connections are made correctly according to the wiring diagram and tightened to the specified torque to prevent overheating and arc faults.

• Overload Protection: A contactor primarily switches loads; it does not provide overload protection for motors. Always combine contactors with appropriate overload relays or motor protection circuit breakers.

• Coil Voltage: Verify that the control voltage supplied to the contactor coil matches its rated coil voltage.

• Environmental Conditions: Install the contactor within its specified ambient temperature and humidity ranges. Avoid excessive dust, vibration, and corrosive atmospheres.

• Maintenance: Periodically check terminals for tightness and inspect contacts for signs of wear or pitting, especially in high-switching frequency applications.

• Safety: Always disconnect power before installing, inspecting, or servicing contactors to prevent electric shock.

Product Applications

Siemens 3-pole contactors are widely used across numerous industries and applications, including:

• Motor Control:

• Starting and stopping three-phase AC motors in pumps, fans, compressors, conveyors, and machine tools.

• Used in direct-on-line (DOL) starters, star-delta starters, and soft starter bypass circuits.

• Heating Systems:

• Switching electric heaters in industrial ovens, furnaces, and HVAC systems.

• Lighting Systems:

• Controlling large lighting banks in commercial buildings, public spaces, and industrial facilities.

• Capacitor Banks:

• Switching power factor correction capacitor banks (requires specific contactor types with pre-insertion resistors).

• Power Distribution:

• As main or branch circuit switches in control panels and distribution boards.

• Automation Systems:

• Interfacing between PLCs and higher power loads.

• Renewable Energy:

• Switching loads in solar and wind power installations.
