Siemens 6BK1100-0GB50-0AA0 Communications Processors

Siemens 6BK1100-0GB50-0AA0 Overview

The Siemens 6BK1100-0GB50-0AA0 is a SIMATIC NET CP 1616 communication processor for connecting a PC or PG/PC to Industrial Ethernet. It provides high-performance Ethernet communication capabilities for PROFINET and TCP/IP applications.

Product Detailed Description

• Function:

• Connects a PC or PG/PC to Industrial Ethernet networks.

• Supports PROFINET IO Controller and PROFINET IO Device functionality.

• Supports TCP/IP communication (e.g., S7 communication, Open TCP/IP).

• Provides a high-performance Ethernet interface.

• Connects to the PC system via a PCI Express (x1) interface.

• Features:

• High-performance Ethernet controller.

• Supports 10/100/1000 Mbit/s (RJ45) Ethernet interfaces.

• Onboard 2-port switch for simplified network topology.

• Supports SNMP (Simple Network Management Protocol).

• Features LED indicators for diagnostics and status display.

• Configuration and diagnostics via SIMATIC NET software.

Product Parameters

• Product Type:

• SIMATIC NET CP 1616 Communication Processor

• Order Number:

• 6BK1100-0GB50-0AA0

• Interfaces:

• Industrial Ethernet: 2 x RJ45, supporting 10/100/1000 Mbit/s

• Bus Interface:

• PCI Express x1

• PROFINET Functions:

• PROFINET IO Controller (Class A)

• PROFINET IO Device (Class B)

• MRP (Media Redundancy Protocol)

• LLDP (Link Layer Discovery Protocol)

• TCP/IP Functions:

• S7 Communication (Server/Client)

• Open TCP/IP Communication (SEND/RECEIVE)

• SNMP

• Power Supply:

• Via PCI Express bus

• Power Consumption:

• Typ. 3.5 W

• Ambient Temperature:

• Operating temperature: 0 °C to +60 °C

• Storage temperature: -25 °C to +70 °C

• Dimensions (W x H):

• Approx. 102 mm x 64 mm (without mounting bracket)

• Operating System Support:

• Please refer to the official Siemens documentation for the latest operating system compatibility information.

Product Advantages

• High-Performance Communication:

• Supports Gigabit Ethernet for fast and reliable data transfer.

• PROFINET Support:

• Full support for PROFINET IO Controller and Device functionality, facilitating integration into PROFINET networks.

• TCP/IP Flexibility:

• Supports various TCP/IP communication methods to meet different application requirements.

• Integrated Switch:

• Onboard 2-port switch simplifies network connections and reduces hardware costs.

• Easy Integration:

• Easy integration into PC systems via the standard PCI Express interface.

• Reliability:

• Siemens SIMATIC NET products are known for their industrial-grade reliability and durability.

• Diagnostic Functions:

• LED indicators and SIMATIC NET software provide comprehensive diagnostic capabilities.

Precautions

• Correct Installation:

• Follow Siemens' installation manual to ensure correct installation into the PCI Express slot.

• Drivers and Software:

• Requires the installation of the correct SIMATIC NET drivers and configuration software for proper operation. Download these from the official Siemens website.

• Power Requirements:

• Ensure the PC system's power supply can meet the power consumption requirements of the CP 1616.

• Environmental Conditions:

• Ensure the operating environment meets the product's temperature and humidity specifications.

• ESD Protection:

• Take appropriate electrostatic discharge (ESD) protection measures during installation and operation.

• Firmware Updates:

• Regularly check for and update the firmware to obtain the latest features and performance improvements.

Product Applications

• Industrial PC Connection:

• Connecting industrial PCs to PROFINET or TCP/IP networks for data acquisition, monitoring, and control.

• PG/PC Connection:

• Allows programming devices (PG/PCs) to communicate with PLCs and other automation devices via Industrial Ethernet.

• High-Performance Data Transfer:

• Suitable for applications requiring high-speed Ethernet communication.

• PROFINET IO Controller/Device:

• Can be used as a PROFINET IO Controller to control IO devices or as a PROFINET IO Device for access by other controllers.

• SCADA Systems:

• Connecting SCADA (Supervisory Control and Data Acquisition) systems to industrial networks.
