Product Detailed Description

• Function: The primary function of the SIPART PS2 is to precisely control the position of a pneumatic control valve (or damper) based on an analog input signal (4-20 mA DC) from a process controller (DCS, PLC, etc.). It continuously compares the actual valve position with the setpoint and adjusts the air pressure to the actuator to maintain the desired position.

• Intelligent Features:

• Auto-tuning: Automatically adjusts its control parameters (PID) to match the specific valve and actuator, optimizing control performance.

• Diagnostic Functions: Provides extensive diagnostic capabilities, including online diagnostics (e.g., sticking detection, friction analysis, valve leakage, valve signature), which help in predictive maintenance and reducing downtime.

• HART Communication: Allows for remote configuration, monitoring, and diagnostics using a HART communicator or a PC with appropriate software (e.g., SIMATIC PDM).

• Non-Contact Position Detection (NCS): Utilizes a wear-free, non-contact method to detect the valve's actual position, ensuring long-term accuracy and reliability without mechanical wear.

• Programmable Characteristic Curves: Allows linear, inverse, or user-defined characteristic curves for flow control.

• Design and Construction:

• Enclosure: Polycarbonate housing, providing good protection against environmental factors.

• Mounting: Designed for universal mounting on linear and part-turn actuators according to NAMUR and VDI/VDE 3845 standards.

• Output: Single-acting (for actuators with spring return).

• Operating Principle: Receives a 4-20 mA input signal. An internal controller (microprocessor-based) calculates the necessary air pressure to achieve the desired valve position. Air is then supplied or vented from the actuator through integrated valves until the actual position matches the setpoint.

Product Parameters

(Note: These parameters are specific to the 6DR5110-0NG00-0AA0 model. Always refer to the official Siemens SIPART PS2 datasheet for the definitive specifications.)

• Model Number: 6DR5110-0NG00-0AA0

• Product Type: Intelligent Valve Positioner

• Input Signal: 4-20 mA DC (analog current signal)

• Communication Protocol: HART

• Operation: Single-acting (for pneumatic actuators with spring return)

• Explosion Protection: Without Ex-protection (Standard design, not for hazardous areas)

• Enclosure Material: Polycarbonate

• Actuator Type: Suitable for both pneumatic linear and part-turn actuators

• Position Detection: Non-contact position detection (NCS)

• Connection Threads:

• Electrical: M20x1.5

• Mechanical/Pneumatic: G1/4

• Limit Monitor: Without limit monitor (no integrated feedback for end positions)

• Option Module: Without option module (no additional I/O or advanced features)

• Power Supply: Supplied via the 4-20 mA current loop.

• Air Supply Pressure: Typically 1.4 to 7 bar (20 to 100 psi), depending on the actuator requirements.

• Accuracy: High positioning accuracy, typically < 0.2% of full scale.

• Repeatability: High repeatability, typically < 0.1% of full scale.

• Operating Temperature: Typically -30 °C to +80 °C (-22 °F to +176 °F).

• Degree of Protection: IP66 / NEMA 4X (typically, check datasheet for exact IP rating).

• Response Time: Fast and dynamic response to changes in setpoint.

• Certification: CE, cULus (for standard version).

Product Advantages

• High Control Accuracy: Ensures precise and stable control of valve position, leading to optimized process quality and efficiency.

• Extensive Diagnostics: Advanced diagnostic capabilities enable predictive maintenance, reducing unplanned downtime and maintenance costs.

• HART Communication: Facilitates remote configuration, calibration, and monitoring, improving operational efficiency and safety.

• Wear-Free Position Detection: Non-contact sensing eliminates mechanical wear, contributing to a longer lifespan and reduced maintenance.

• Auto-tuning Function: Simplifies commissioning and ensures optimal control performance for various valve/actuator combinations.

• Robust Design: Polycarbonate housing provides excellent protection against harsh industrial environments.

• Universal Mounting: Compatible with a wide range of linear and part-turn actuators, offering flexibility in application.

• Energy Efficiency: Optimized air consumption reduces operational costs.

Precautions

• Correct Selection: Ensure the positioner type (single-acting/double-acting), communication protocol (HART), and enclosure material (polycarbonate) are suitable for the specific application and environmental conditions.

• Air Supply Quality: Provide clean, dry, oil-free instrument air to the positioner. Contaminated air can cause blockages and damage to the internal pneumatic components. Install proper filters and regulators.

• Proper Installation: Follow the Siemens installation manual carefully. Ensure correct mounting on the valve/actuator, proper pneumatic connections, and correct electrical wiring (4-20 mA loop).

• Calibration and Tuning: While auto-tuning is available, initial calibration and fine-tuning may be necessary to achieve optimal performance. Ensure the positioner is correctly calibrated to the full stroke of the valve.

• Environmental Conditions: Operate the positioner within its specified temperature and humidity ranges. Protect it from excessive vibration or direct mechanical impact.

• Hazardous Area: This specific model (6DR5110-0NG00-0AA0) is WITHOUT Ex-protection. Do NOT install it in hazardous (explosive) atmospheres. For such environments, select an intrinsically safe or explosion-proof SIPART PS2 variant.

• Firmware and Software: Use compatible Siemens software (e.g., SIMATIC PDM) for advanced configuration and diagnostics.

Product Applications

The Siemens SIPART PS2 intelligent valve positioners are indispensable in various process industries for controlling pneumatic final control elements.

• Chemical and Petrochemical:

• Controlling flow, pressure, and level of chemicals in reactors, distillation columns, and pipelines.

• Precise regulation of critical process parameters.

• Oil & Gas:

• Control of valves in refineries, offshore platforms, and pipeline systems.

• Actuating choke valves and emergency shutdown valves.

• Power Generation:

• Controlling steam valves, boiler feedwater valves, and damper positions.

• Ensuring precise combustion control.

• Water and Wastewater Treatment:

• Regulating flow rates of water and chemicals, controlling valve positions in filtration and pumping stations.

• Pharmaceutical and Food & Beverage:

• Precise control of hygienic valves for batch processes, temperature, and flow regulation.

• Mining and Metals:

• Controlling valves in mineral processing, slurry lines, and material handling systems.

• Pulp & Paper:

• Regulating chemical flows, steam control, and stock preparation processes.

• HVAC (Industrial):

• Controlling large air dampers and steam valves for precise climate control in industrial facilities.
