Siemens 6EP1336-3BA00 Compact single-phase power supply

Siemens SITOP PSU100C 6EP1336-3BA00 Overview

The Siemens SITOP PSU100C 6EP1336-3BA00 is a compact, single-phase power supply that provides a stable 24 V DC output voltage and an output current of 10 A. It is part of the SITOP PSU100C series, which is known for its small design, powerful performance, and competitive price.

Product Detailed Description

• Function:

• Converts single-phase AC input voltage into a stable 24 V DC output voltage.

• Supplies power to loads in various industrial and automation applications.

• Features short-circuit protection, overload protection, and overvoltage protection.

• Integrated Power Boost function provides up to 1.5 times the rated current for a short duration to start loads with high inrush currents.

• LED indicator for displaying the operating status of the power supply.

• Features:

• Compact design saves space in the control cabinet.

• Wide input voltage range for global use on different mains.

• High efficiency reduces energy loss and heat generation.

• High reliability and long service life.

• DIN rail mounting for easy and quick installation.

• Integrated input fuse for additional protection.

Product Parameters

• Input Voltage:

• 120/230 V AC (single-phase)

• Range: 85-264 V AC

• Output Voltage:

• 24 V DC (adjustable range: 22.8-25.2 V DC)

• Output Current:

• 10 A

• Power Boost:

• 15 A for 5 s

• Efficiency:

• Typ. 90%

• Protection Functions:

• Short-circuit protection: Constant current limitation

• Overload protection: Constant current limitation

• Overvoltage protection: < 33 V DC

• Input Inrush Current Limitation:

• Typ. 15 A at 230 V AC

• Power Factor:

• 0.5

• Ambient Temperature:

• Operating temperature: -25 °C to +70 °C (derating above +55 °C)

• Storage temperature: -40 °C to +85 °C

• Degree of Protection:

• IP20

• Connection Method:

• Screw terminals

• Dimensions (W x H x D):

• 70 mm x 90 mm x 75 mm

• Weight:

• Approx. 0.4 kg

• Mounting:

• DIN rail mounting

• Certifications:

• CE, cULus, EAC

Product Advantages

• Compact Design:

• Saves control cabinet space, suitable for space-constrained applications.

• High Reliability:

• Robust and durable with comprehensive protection functions ensuring stable system operation.

• Wide Input Voltage Range:

• Suitable for global use on different mains, facilitating international applications.

• Power Boost Function:

• Enables reliable starting of loads with high inrush currents.

• High Efficiency:

• Reduces energy loss, lowering operating costs and heat generation.

• Easy Installation:

• DIN rail mounting and clear terminal markings for quick and easy installation.

• High Cost-Effectiveness:

• Offers a good balance between performance and price.

Precautions

• Correct Selection:

• Choose the appropriate power supply model based on the voltage and current requirements of the load.

• Correct Installation:

• Follow Siemens' installation guidelines, ensuring the power supply is securely mounted and correctly electrically connected.

• Ensure adequate ventilation to prevent overheating.

• Derating:

• Derating may be necessary at higher ambient temperatures or during continuous full-load operation to extend the power supply's lifespan. Refer to the derating curve in the product manual.

• Safe Operation:

• Adhere to electrical safety regulations to ensure the safety of operating personnel.

• Grounding:

• Ground the power supply correctly as required.

Product Applications

• Industrial Automation:

• Powering control system components such as PLCs, HMIs, sensors, and actuators.

• Mechanical Engineering:

• Powering machine tools, packaging machinery, etc.

• Building Automation:

• Powering lighting, control systems, etc.

• Process Control:

• Powering various process control equipment.

• Other applications requiring a stable 24 V DC power supply.
