Siemens 6EP1344-3BA00 Power Module

Siemens SITOP smart 6EP1344-3BA00 Overview

The Siemens SITOP smart 6EP1344-3BA00 is a single-phase regulated power supply belonging to the SITOP smart series. This series of power supplies features a compact design and powerful functionality, making it suitable for various industrial applications.

Product Detailed Description

• Function:

• Converts single-phase AC input voltage into a stable DC output voltage.

• Provides overload and short-circuit protection to ensure the safety of connected devices.

• Features a Power boost function to provide extra power for a short period to handle inrush currents and other demands.

• High reliability, designed for industrial environments.

• Features:

• Compact design, saving installation space.

• Wide input voltage range, suitable for different power grids.

• Adjustable output voltage to accommodate different device requirements.

• LED indicator for displaying operating status.

• DIN rail mounting for easy and quick installation.

Product Parameters

• Input Voltage:

• Single-phase AC 120/230 V (range: 85-264 V AC)

• Output Voltage:

• DC 24 V (adjustable range: 22.8-25.2 V DC)

• Output Current:

• 5 A

• Power boost:

• 6 A for 5 seconds

• Efficiency:

• Typical 90%

• Protection Functions:

• Overload protection (constant current characteristic)

• Short-circuit protection (automatic restart)

• Over-temperature protection

• Connection Method:

• Screw terminals

• Protection Class:

• IP20

• Ambient Temperature:

• Operating temperature: -25 °C to +70 °C (derating above +60 °C)

• Storage temperature: -40 °C to +85 °C

• Dimensions (W x H x D):

• 70 mm x 90 mm x 75 mm

• Weight:

• Approx. 0.3 kg

• Standards Compliance:

• CE, UL, cUL, CB

Product Advantages

• Compact Design:

• Saves space within the control cabinet.

• High Efficiency:

• Reduces energy consumption and heat generation.

• High Reliability:

• Industrial-grade design ensures stable operation for extended periods.

• Power Boost Function:

• Easily handles the inrush current demands of devices.

• Wide Input Voltage Range:

• Suitable for different power grids worldwide.

• Easy Installation:

• Quick and easy DIN rail mounting.

• High Cost-Effectiveness:

• Offers a good balance between performance and price.

Precautions

• Correct Installation:

• Follow Siemens' installation guidelines, ensuring the power supply is securely mounted with sufficient ventilation space.

• Correct Wiring:

• Connect the input and output cables correctly according to the wiring diagram, ensuring correct polarity.

• Environmental Conditions:

• Avoid using the power supply in environments exceeding its operating temperature and humidity ranges.

• Avoid using it in environments with corrosive gases or dust.

• Overload Protection:

• Although the power supply has overload protection, avoid prolonged operation beyond its rated output current.

• Maintenance:

• Regularly check if the power supply connections are loose and clean the surface dust.

Product Applications

• Industrial Automation:

• Powering control system components such as PLCs, sensors, and actuators.

• Mechanical Engineering:

• Powering machine tools, robots, and other equipment.

• Building Automation:

• Powering lighting, HVAC, and other systems.

• Process Control:

• Powering transmitters, controllers, and other instruments.

• Other applications requiring a stable and reliable 24 V DC power supply.
