Siemens 6ES7441-1AA04-0AE0 Communications Processors

Siemens 6ES7441-1AA04-0AE0 Overview

The Siemens 6ES7441-1AA04-0AE0 is a CP 441-1 communication processor for the SIMATIC S7-400 series. It is used to connect S7-400 controllers to various communication networks and protocols, enabling data exchange and system integration.

Product Detailed Description

• Function:

• Provides a communication interface between the SIMATIC S7-400 system and Industrial Ethernet.

• Supports TCP/IP and UDP protocols.

• Used for communication with programming devices, operator control and monitoring systems, and other automation devices.

• Supports S7 communication, PG/OP communication, and open IE communication.

• Integrated 10/100 Mbit/s Ethernet interface.

• Features:

• High-performance communication interface.

• Easy to configure and integrate into the S7-400 system.

• Supports various communication services.

• Rugged industrial design.

• LED indicators for diagnosing communication status.

Product Parameters

• Order Number: 6ES7441-1AA04-0AE0

• Product Name: SIMATIC S7-400, CP 441-1 Communication processor

• Communication Interface: 1 x RJ45 port for Industrial Ethernet (10/100 Mbit/s)

• Supported Protocols:

• TCP/IP

• UDP

• ISO-on-TCP (RFC 1006)

• S7 communication (server/client)

• PG/OP communication

• Open IE communication (SEND/RECEIVE)

• Supported Communication Services:

• Ethernet/IP (client)

• PROFINET IO (controller/device) - license required

• SNMP

• DHCP

• NTP

• Supply Voltage: 5 V DC (via backplane bus)

• Power Consumption: Typ. 3.5 W

• Front Panel Indicators: POWER, RUN, ERROR, MAINT, IF

• Installation: Mounted next to the CPU in the S7-400 rack

• Ambient Temperature: 0 °C to +60 °C

• Protection Class: IP20

• Dimensions (WxHxD): 25 mm x 290 mm x 220 mm

• Weight: Approx. 0.29 kg

• Firmware Version: Refer to the product label or manual for the specific version

Product Advantages

• High-Performance Communication: Provides fast and reliable Ethernet communication capabilities.

• System Integration: Easy integration into SIMATIC S7-400 control systems.

• Flexibility: Supports various Industrial Ethernet protocols and services.

• Reliability: Rugged industrial design suitable for harsh environments.

• Ease of Use: Convenient configuration and diagnostics via STEP 7.

• Scalability: Allows the S7-400 system to connect to a wider range of networks and devices.

Precautions

• Correct Installation: Install the CP 441-1 module correctly into the S7-400 rack according to Siemens' installation guidelines.

• Power Connection: The CP 441-1 is powered via the backplane bus, ensure sufficient power supply to the S7-400 system.

• Network Configuration: Configure the IP address and other network parameters correctly using STEP 7 or other appropriate tools.

• Software Compatibility: Ensure the STEP 7 version used is compatible with the firmware version of the CP 441-1.

• Environmental Conditions: Ensure the operating environment meets the temperature and humidity specifications of the CP 441-1.

• License Management: A corresponding license may be required for PROFINET IO functionality.

Product Applications

• Industrial Automation: Connecting S7-400 controllers to higher-level monitoring systems (SCADA/HMI).

• Networked Control Systems: Building distributed control systems with communication between controllers.

• Data Acquisition and Transmission: Transferring process data to plant networks or the internet.

• Remote Maintenance and Diagnostics: Enabling remote programming and troubleshooting via Ethernet.

• Integration with Other Devices: Connecting S7-400 systems to other automation devices that support Industrial Ethernet protocols.
