Siemens 6GK1415-2AA10 Access Point

The Siemens SCALANCE W788-2 M12 (6GK1415-2AA10) is a rugged, industrial Wireless Local Area Network (WLAN) Access Point designed for reliable wireless communication in demanding industrial environments. It provides robust wireless connectivity for industrial automation applications, especially where standard office WLAN devices would not suffice due to harsh conditions. The "M12" in its name signifies the use of robust M12 connectors, which are ideal for vibration-prone and dust/water-exposed industrial settings.

Product Detailed Description

• Functionality: This access point enables wireless communication between WLAN-capable devices (like industrial PCs, mobile panels, AGVs, or other SCALANCE W devices configured as clients) and a wired industrial Ethernet network. It acts as a central hub for wireless data exchange within a specific area.

• WLAN Standard: Supports IEEE 802.11a/b/g/n, providing high data rates (up to 300 Mbit/s in 802.11n mode) and operating in both 2.4 GHz and 5 GHz frequency bands. The dual-band capability allows for flexibility in avoiding interference and ensures reliable communication.

• Robust Industrial Design:

• Features a compact, metal housing for durability and electromagnetic compatibility (EMC).

• Equipped with M12 connectors for power, Ethernet, and antennas, ensuring robust and vibration-proof connections, and high ingress protection.

• Designed for extended temperature ranges and high shock/vibration resistance.

• Security Features: Incorporates advanced security mechanisms such as WPA2, IEEE 802.1x, and firewall functionality to protect the wireless network from unauthorized access.

• Redundancy and Reliability: Supports features like iFeatures (Intelligent Features) for increased network reliability and diagnostics, such as redundant power supply inputs.

• Management: Can be easily configured and managed via a web-based interface (WBM), SNMP, or with network management software like SINEMA Server.

• Mounting: Designed for versatile mounting options, including DIN rail, wall, or ceiling mounting.

Product Parameters

(Note: These are typical parameters for the SCALANCE W788-2 M12 series. Always refer to the official Siemens data sheet and manual for the 6GK1415-2AA10 for precise specifications.)

• Order Number: 6GK1415-2AA10

• WLAN Standard: IEEE 802.11a/b/g/n

• Frequency Bands:

• 2.4 GHz (802.11b/g/n): 2.412 GHz to 2.472 GHz

• 5 GHz (802.11a/n): 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz (country-specific regulations apply)

• Data Rate (max.): Up to 300 Mbit/s (with 802.11n, MIMO 2x2)

• Antenna Connectors: 2 x R-SMA (M12 type for robust connection, requires specific M12-R-SMA adapter cables/antennas)

• Ethernet Ports: 2 x RJ45 (M12 D-coded for robust industrial Ethernet connection)

• Power Supply:

• Rated Voltage: 24 V DC (redundant power supply possible)

• Permissible Range: 19.2 V DC to 28.8 V DC

• Power Consumption: Typically 8 W to 12 W (depending on operating mode)

• Degree of Protection: IP65/IP67 (depends on correct use of M12 connectors)

• Operating Temperature: -20 °C to +60 °C (or wider, typically -40°C to +70°C for some variants, check exact datasheet)

• Storage Temperature: -40 °C to +85 °C

• Relative Humidity: 95% non-condensing

• Dimensions (W x H x D): Approx. 140 mm x 140 mm x 50 mm (compact industrial form factor)

• Mounting: DIN rail, wall mounting, ceiling mounting

• Certifications: CE, FCC, IC, UL, cUL, ATEX/IECEx (for hazardous locations, if applicable to specific variant), NEMA TS2 (for traffic applications, if applicable to specific variant).

Product Advantages

• Extreme Robustness: M12 connectors and a metal housing ensure high resistance to vibration, shock, dust, and water (IP65/IP67), making it ideal for harsh industrial environments like manufacturing floors, outdoor installations, or mobile applications.

• High Performance: Supports IEEE 802.11n with MIMO technology, providing high data rates and reliable wireless connections, even with challenging radio propagation conditions.

• Dual-Band Capability (2.4/5 GHz): Offers flexibility to utilize the less congested 5 GHz band, reducing interference and improving overall wireless performance and reliability.

• Industrial Security: Integrated security features protect sensitive industrial data and prevent unauthorized network access.

• Reliability Features: Redundant power supply inputs and diagnostic capabilities enhance network availability.

• Siemens Integration: Seamless integration into Siemens TIA Portal and other Siemens industrial automation solutions.

• Easy Commissioning & Management: Web-based management and SNMP support simplify configuration and ongoing network monitoring.

• Future-Proof: Adherence to industrial WLAN standards ensures compatibility and longevity.

Precautions

• Antenna Selection and Placement: Proper selection of antennas (directional vs. omnidirectional) and their optimal placement are critical for achieving desired coverage and link quality. Use industrial-grade antennas compatible with M12 connectors.

• M12 Connector Usage: Always use appropriate M12 cables and connectors (for Ethernet, power, and antennas) to maintain the specified IP protection class and ensure reliable connections in vibrating environments.

• Power Supply: Ensure a stable 24V DC power supply is provided, meeting the required current draw. Consider redundant power supply for critical applications.

• Environmental Limits: Do not exceed the specified operating temperature, humidity, and vibration limits. While robust, extreme conditions can still affect performance.

• Radio Planning: For optimal performance, especially in complex industrial facilities, conduct thorough radio planning (site surveys) to identify potential interference sources, optimize access point placement, and determine antenna types.

• Security Configuration: Properly configure all security features (WPA2, authentication, firewall rules) to prevent unauthorized access to the industrial network.

• Firmware Updates: Regularly check for and apply firmware updates from Siemens to ensure optimal performance, security, and bug fixes.

• Interference: Be aware of potential interference from other wireless devices (e.g., Bluetooth, other WLANs, microwave ovens) or industrial equipment (e.g., motors, welders) and mitigate them through frequency planning or shielding.

• Grounding: Ensure proper grounding of the access point and antennas for optimal performance and safety.

Product Applications

The Siemens SCALANCE W788-2 M12 Access Point is ideal for a wide range of demanding industrial applications requiring reliable and robust wireless communication:

• Automated Guided Vehicles (AGVs) / Automated Mobile Robots (AMRs): Providing wireless communication for navigation, control, and data exchange.

• Material Handling Systems: Wireless connectivity for conveyors, sorting systems, and robotic cells in warehouses and logistics.

• Manufacturing Plants: Enabling flexible production lines, wireless tool control, and mobile operator panels.

• Cranes and Hoists: Wireless control and monitoring for overhead cranes, gantry cranes, and mobile lifting equipment.

• Harsh Industrial Environments: Applications in dusty, humid, vibrating, or temperature-extreme areas where standard WLAN devices would fail.

• Outdoor Applications: Suitable for outdoor use (with appropriate enclosure/protection if needed, given IP rating) in areas like port terminals, mining operations, or construction sites.

• Intralogistics: Providing wireless infrastructure for tracking and managing goods within industrial facilities.

• Machine Building: Integrating wireless capabilities directly into machinery for diagnostics, remote control, or flexible operation.
