Siemens 6GK1503-3CA00 Communication Card

Siemens SIMATIC NET CP 5613 A2 Overview

The Siemens SIMATIC NET CP 5613 A2 (Order No. 6GK1503-3CA00) is a communication card used to connect PG/PCs or HMI devices to the PROFIBUS network. It is a powerful and reliable interface for industrial automation applications.

Product Detailed Description

• Function:

• Provides electrical isolation and data transmission between a PG/PC or HMI device and the PROFIBUS network.

• Supports PROFIBUS DP master and slave functionality.

• Supports PROFIBUS FMS and PG/OP communication.

• Allows for programming, diagnostics, and data exchange via the PROFIBUS network.

• Offers high performance for fast and reliable data transmission.

• Features:

• PCI bus interface.

• Supports PROFIBUS transmission rates up to 12 Mbit/s.

• Integrated microprocessor for handling communication tasks, relieving the host CPU.

• Provides LED indicators for diagnosing communication status.

• Compact design for easy installation in standard PCs.

• Robust industrial design suitable for industrial environments.

• Requires the installation of corresponding SIMATIC NET software components.

Product Parameters

• Order Number: 6GK1503-3CA00

• Interface: PROFIBUS (RS485)

• Connector: 9-pin D-sub connector

• PCI Bus: 3.3 V or 5 V PCI bus

• Transmission Rate: 9.6 kbit/s to 12 Mbit/s

• PROFIBUS Functionality:

• DP Master (Class 1 and Class 2)

• DP Slave

• FMS

• PG/OP Communication

• Electrical Isolation: Yes

• Power Consumption: Typ. 3 W

• Ambient Temperature:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: -25 °C to +70 °C

• Relative Humidity: 5% to 95% (non-condensing)

• Dimensions (W x H): Approx. 121 x 100 mm (without mounting bracket)

• Weight: Approx. 110 g

• Supported Operating Systems: Refer to the relevant SIMATIC NET software documentation

• Required Software: SIMATIC NET software components (e.g., SOFTNET-DP, SOFTNET-S7)

Product Advantages

• High-Performance Communication: Supports transmission rates up to 12 Mbit/s for fast and reliable data exchange.

• Versatility: Supports PROFIBUS DP master and slave functionality, as well as FMS and PG/OP communication.

• Easy Integration: Standard PCI bus interface for easy installation in common PC systems.

• High Reliability: Robust industrial design suitable for industrial environments.

• Relieves Host CPU: Integrated microprocessor handles communication tasks.

• Status Indication: LED indicators for easy diagnosis of communication status.

• Electrical Isolation: Provides electrical isolation for enhanced system reliability.

Precautions

• Correct Installation: Follow Siemens' installation guidelines, ensuring the card is correctly inserted into the PCI slot and secured.

• Software Installation: Requires the installation of compatible SIMATIC NET software components for proper operation. Refer to the software documentation for operating system compatibility and installation instructions.

• PROFIBUS Cables and Connectors: Use PROFIBUS-compliant cables and connectors to ensure reliable physical connections.

• Termination Resistors: Proper termination resistors must be connected at the physical ends of the PROFIBUS network.

• Power Requirements: Ensure the PC power supply can provide sufficient power.

• ESD Protection: Observe electrostatic discharge (ESD) precautions when handling the communication card.

• Diagnostics: Use SIMATIC NET diagnostic tools for troubleshooting.

Product Applications

• Connecting Programming Devices (PG) to the PROFIBUS Network: For uploading, downloading, and online monitoring of PLC programs.

• Connecting Operator Panels (OP/HMI) to the PROFIBUS Network: For visualization and control of machines and processes.

• As a PROFIBUS DP Master: Controlling PROFIBUS DP slave devices (e.g., I/O modules, drives, sensors).

• As a PROFIBUS DP Slave: Allowing the PC system to act as a slave in the PROFIBUS network for receiving or sending data.

• Data Acquisition and Monitoring Systems: Integrating PC systems into the PROFIBUS network for acquiring process data and monitoring.

• Simulation and Testing Systems: For simulating the behavior of devices in a PROFIBUS network.
