SIEMENS 6SL3200-0ST07-0AA0 Inverter Connector Kit

1. Product Description

This kit provides an integrated solution for the proper grounding and electromagnetic compatibility (EMC) of power and control cables. In industrial environments, high-frequency interference from motor cables can disrupt sensitive electronics. This shield connection kit ensures that cable shields are grounded directly to the inverter's chassis with a low-impedance path.

2. Technical Specifications

3. Product Advantages

• EMC Compliance: Significantly reduces Electromagnetic Interference (EMI) by providing a 360-degree shield contact, ensuring the system meets industrial emission standards.

• Mechanical Stability: Acts as a strain relief for motor and power cables, preventing physical stress on the inverter terminals.

• Simplified Installation: Specifically engineered for the V20 FSD housing; it attaches directly to the bottom of the drive without the need for custom drilling.

• Durability: Made of corrosion-resistant materials suitable for harsh industrial cabinet environments.

4. Key Considerations & Precautions

• Frame Size Matching: This kit is only for Frame Size D. Using it on smaller frame sizes (FSA/FSB/FSC) or larger ones (FSE) will result in a physical mismatch.

• Cable Stripping: For the shield to be effective, the outer insulation of the cable must be stripped back so the braided shield makes direct metal-to-metal contact with the clamps.

• Tightening Torque: Ensure mounting screws are tightened to the specified torque in the manual to maintain a low-impedance ground path.

• Safety: Always ensure the inverter is powered off and the DC link capacitors are discharged before installing the kit.

5. Typical Applications

This component is used wherever a SINAMICS V20 (Frame Size D) drive is installed in a system requiring high reliability and noise suppression, such as:

• Pumping & Ventilation: Large-scale HVAC systems and water treatment plants.

• Conveyor Systems: Material handling in manufacturing lines.

• Compressors: Industrial air compression units.

• Processing Machinery: Mixers, grinders, and centrifuges where precise control signals must be protected from motor noise.
