SIEMENS 6SL32020AE210CA0 Output module

Siemens SINAMICS V20 Inverter Overview

The Siemens SINAMICS V20 (Order No. 6SL3202-0AE21-0CA0) is a cost-effective, high-performance inverter primarily used for speed control of three-phase AC induction motors in basic applications. It is known for its ease of use, compact design, and excellent price-performance ratio.

Product Detailed Description

• Function:

• Controls the speed of three-phase AC induction motors.

• Provides motor starting, stopping, acceleration, and deceleration control.

• Supports V/f control mode.

• Features basic protection functions such as overcurrent, overvoltage, overload, and overtemperature protection.

• Integrated PID controller for simple process control applications.

• Supports USS and Modbus RTU communication protocols.

• Features:

• Compact design, saving installation space.

• Easy to install and commission.

• Simple and quick basic parameter setting.

• Robust and durable, suitable for industrial environments.

• High cost-effectiveness.

• Integrated braking chopper (some models).

Product Parameters

• Order Number: 6SL3202-0AE21-0CA0

• Power Rating: 0.75 kW (1 hp)

• Input Voltage: 380-480 V AC, 3-phase

• Input Frequency: 47-63 Hz

• Output Voltage: 0-Input Voltage

• Output Frequency: 0-650 Hz

• Control Mode: V/f (Linear V/f, Quadratic V/f, Programmable V/f)

• Overload Capacity: 150% rated current for 60 seconds

• Degree of Protection: IP20

• Cooling Method: Natural cooling

• Ambient Temperature: -10 °C to +50 °C (non-condensing)

• Communication Interface: USS, Modbus RTU

• Digital Inputs: 4

• Analog Inputs: 1 (0-10V, 0/4-20mA selectable)

• Digital Outputs: 1 (Relay normally open contact)

• Analog Outputs: 0

• Braking Chopper: Not integrated

• Dimensions (W x H x D): 73 mm x 173 mm x 155 mm

• Mounting Method: Screw mounting

• Certifications: CE, UL, cUL, EAC, KC

Product Advantages

• Easy to Use:

• Simple installation and commissioning.

• Quick and easy basic parameter setting.

• Compact Design:

• Saves installation space, suitable for small machinery.

• High Cost-Effectiveness:

• Economical solution for basic applications.

• Robust and Durable:

• Suitable for industrial environments.

• Integrated PID Control:

• Can be used for simple closed-loop process control.

• Supports Common Communication:

• USS and Modbus RTU facilitate connection to higher-level control systems.

Precautions

• Correct Selection:

• Select the appropriate inverter model based on motor power and load characteristics.

• Correct Installation:

• Follow Siemens' installation guidelines, ensuring the inverter is installed in a well-ventilated area with suitable ambient temperature.

• Correct Wiring:

• Connect the power supply, motor, and control signal lines correctly according to the wiring diagram, ensuring proper grounding.

• Parameter Settings:

• Set the inverter parameters correctly according to the specific motor and application requirements.

• EMC Considerations:

• Take necessary electromagnetic compatibility (EMC) measures to reduce electromagnetic interference.

• Safe Operation:

• Always follow relevant safety procedures when operating and maintaining the inverter.

• Braking Resistor:

• If frequent braking or rapid deceleration is required, an external braking resistor needs to be connected.

Product Applications

The SINAMICS V20 inverter (6SL3202-0AE21-0CA0) is suitable for the following basic applications:

• Pumps: Speed control, energy-saving operation.

• Fans: Flow control, noise reduction.

• Conveyors: Simple speed control.

• Mixers: Basic speed adjustment.

• Gates and Roller Shutters: Simple motion control.

• Other Basic Machinery: Applications that do not require complex control functions.
