Yokogawa PK200-A33 Output module

Product Description

The Yokogawa PK200-A33 is a current-to-pneumatic (I/P) converter that efficiently transforms electrical signals into proportional pneumatic output. It is commonly used in industrial process control applications

where pneumatic actuators are employed. This device plays a crucial role in bridging the gap between electronic control systems and pneumatic final control elements.

Key Features and Specifications

• Input Signal: 4-20 mA DC or 10-50 mA DC



• Output Signal: 20-100 kPa (Standard Output) or 40-200 kPa (Doubled output)



• Linearity: ±0.2% of span



• Hysteresis: 0.2% of span



• Repeatability: 0.1% of span



• Operating Temperature: -40 to 80°C



  Air Supply: 140 kPa (Standard Output) or 240 kPa (Doubled output)



  Mounting: Surface or 2-inch pipe




Advantages

• High Accuracy: Offers excellent linearity, hysteresis, and repeatability for precise control.



• Reliability: Designed for rugged industrial environments and provides long-term stability.

• Flexibility: Can be configured for various input and output ranges.

• Efficiency: Low air consumption and high output air capacity.



• Ease of Use: Simple to install and configure.

Precautions

• Air Supply: Ensure a clean and dry air supply to prevent contamination.

• Grounding: Proper grounding is essential for electrical safety.

• Installation: Follow the manufacturer's instructions carefully to avoid damage.

• Maintenance: Regular inspection and calibration are recommended for optimal performance.

Applications

• Process Control: Used to actuate control valves, dampers, and other pneumatic devices in process industries such as chemical, petrochemical, and power generation.

• HVAC: Controls pneumatic actuators in heating, ventilation, and air conditioning systems.

• Manufacturing: Used in various manufacturing processes to control pneumatic equipment.

Additional Notes

• Zero and Span Adjustment: The PK200-A33 allows for both zero and span adjustments to fine-tune the output.

• Auto/Manual Transfer Switch: An optional feature that allows for manual adjustment of the output signal.



• Material Compatibility: Ensure compatibility of wetted parts with the process fluid.

In summary, the Yokogawa PK200-A33 is a robust and reliable I/P converter that plays a vital role in industrial process control. Its high accuracy, flexibility, and ease of use make it a popular choice for a wide range

 of applications.

For more detailed information and specific product recommendations, please refer to the Yokogawa product catalog or consult with a Yokogawa authorized distributor.
