Yokogawa YHC5150X Output module

Brand: YOKOGAWA

Model number:YHC5150X

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.18kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Yokogawa YHC5150X Output module


INQUIRE NOW

Products Name: Yokogawa YHC5150X Output module

PRODUCT DESCRIPTION

Yokogawa YHC5150X HART Communicator Overview

The Yokogawa YHC5150X is a rugged and robust handheld device designed for configuring, calibrating, maintaining, and troubleshooting HART (Highway Addressable Remote Transducer) devices. It is a versatile tool suitable for a wide range of industrial automation applications.

Product Detailed Description

  • Function:

    • Configures, calibrates, and maintains HART field devices.

    • Monitors process variables, device status, and diagnostic information.

    • Performs valve stroke tests and calibration.

    • Saves and loads device configurations.

    • Provides an intuitive user interface for easy operation.

    • Supports multiple languages.

    • Features intrinsic safety certification for use in hazardous areas.

  • Features:

    • Rugged and durable handheld design for industrial environments.

    • Large color touchscreen display for easy reading and operation.

    • Supports HART, WirelessHART, and FOUNDATION fieldbus devices.

    • Built-in Bluetooth and USB communication interfaces.

    • Rechargeable lithium-ion battery with long battery life.

    • Integrated HART DD (Device Description) library for supporting various HART devices.

    • Offers online help and diagnostic functions.

Product Parameters

  • Supported Protocols:

    • HART

    • WirelessHART

    • FOUNDATION fieldbus

  • Display:

    • Size: 4.3 inches

    • Type: TFT Color Touchscreen

    • Resolution: 480 x 272 pixels

  • Power Supply:

    • Battery: Rechargeable Lithium-ion battery

    • Battery Life: Typically 10 hours

    • Charging Time: Approximately 3 hours

  • Communication Interfaces:

    • HART: Built-in

    • WirelessHART: Via optional adapter

    • FOUNDATION fieldbus: Via optional adapter

    • Bluetooth: Built-in

    • USB: Mini-B

  • Memory:

    • Internal Memory: 2 GB

    • SD Card Slot: Supports up to 32 GB

  • Ambient Temperature:

    • Operating Temperature: -10 to +55 °C (14 to 131 °F)

    • Storage Temperature: -20 to +60 °C (-4 to 140 °F)

  • Protection Degree:

    • IP54

  • Intrinsic Safety Certification:

    • ATEX, IECEx, FM, CSA (depending on the specific model)

  • Dimensions (W x H x D):

    • 93 mm x 228 mm x 52 mm (3.7 in x 9.0 in x 2.0 in)

  • Weight:

    • Approximately 500 g (1.1 lb)

Product Advantages

  • Versatility:

    • Supports HART, WirelessHART, and FOUNDATION fieldbus devices, making it a multi-functional tool.

  • Ease of Use:

    • Intuitive color touchscreen interface for simple and convenient operation.

  • Ruggedness:

    • Robust industrial design suitable for harsh field environments.

  • Powerful Functionality:

    • Provides comprehensive device configuration, calibration, maintenance, and diagnostic capabilities.

  • Wireless Communication:

    • Built-in Bluetooth for easy data transfer and connectivity.

  • Intrinsic Safety:

    • Features intrinsic safety certification for safe use in hazardous areas.

  • Expandability:

    • Supports SD card for expanding storage capacity.

Precautions

  • Correct Operation:

    • Carefully read and follow the operating instructions in the user manual.

  • Safe Usage:

    • Ensure the device has the appropriate intrinsic safety certification when used in hazardous areas.

  • Battery Maintenance:

    • Charge and maintain the battery correctly according to the instructions to prolong battery life.

  • Software Updates:

    • Regularly update the DD library and firmware in the device to support the latest HART devices and features.

  • Dust and Water Resistance:

    • While it has a certain degree of protection, avoid using it in extremely harsh environments.

  • Calibration:

    • Calibrate the YHC5150X periodically to ensure measurement accuracy.

Product Applications

  • Process Industries:

    • Oil and Gas

    • Chemical

    • Pharmaceutical

    • Power

    • Water and Wastewater Treatment

  • Equipment Maintenance:

    • Configuration, calibration, and troubleshooting of field devices.

    • Maintenance and testing of valves and actuators.

  • Commissioning and Startup:

    • Configuration and verification of newly installed HART devices.

  • Factory Acceptance Tests (FAT):

    • Verifying the correct configuration and functionality of HART devices.

  • Asset Management:

    • Collecting and managing configuration and diagnostic information of HART devices.
