Yaskawa J1000 (220V) Output module

Product Description

The Yaskawa J1000 is a compact and versatile variable frequency drive (VFD) designed to control the speed of AC induction motors. It is particularly well-suited for a wide range of industrial applications where precise speed control and energy efficiency are paramount. The 220V version is designed for single-phase power supply.

Key Features and Specifications

• Voltage: 220V single-phase

• Power Range: Available in various horsepower ratings, typically from fractional to several horsepower.



• Control Modes: Offers a variety of control modes, including V/F control, sensorless vector control, and PID control.

• Protection Features: Built-in protection features such as overload, overcurrent, overvoltage, and undervoltage protection.

• Communication: Supports various communication protocols for integration into automation systems.



• Compact Design: Offers a compact and lightweight design for easy installation in tight spaces.



Advantages

• Energy Efficiency: Provides efficient motor control, reducing energy consumption and operating costs.

• Precise Speed Control: Offers precise speed control for a wide range of applications.

• Easy to Use: User-friendly interface and programming.

• Reliable: Built with high-quality components for reliable operation.

• Flexible: Can be adapted to a variety of applications through various control modes and options.



Precautions

• Installation: Follow the manufacturer's installation instructions carefully.

• Wiring: Ensure correct wiring to avoid damage to the drive and connected equipment.

• Cooling: Provide adequate ventilation to prevent overheating.

• Grounding: Proper grounding is essential for safety and performance.

• Maintenance: Regular maintenance is recommended to ensure optimal performance and longevity.

Applications

• Conveyor Systems: Controlling the speed of conveyor belts for precise material handling.

• Pumps: Controlling the flow rate of liquids in pumping applications.



• Fans: Regulating airflow in HVAC systems and industrial processes.

• Machine Tools: Controlling the speed of machine tools for various machining operations.

• Textile Machinery: Used in textile machinery for precise speed control of spindles and other components.

Additional Information

For more detailed information, including specific models, technical specifications, and application examples, please refer to the official Yaskawa product documentation or contact a Yaskawa authorized distributor.
