Yaskawa USAFED-30C220E REV H Digital Qutput Termination

Product Detailed Description

• Function:

• Converts electrical energy into precise mechanical motion (rotation).

• Designed for closed-loop control systems where accurate position, speed, and torque are critical.

• Utilizes a permanent magnet rotor and is driven by three-phase electricity controlled by a servo amplifier.

• The integrated encoder (e.g., UTOPH-81AWF) provides real-time feedback on the motor's position and speed to the servo amplifier, enabling precise control and error correction.

• Features:

• Brushless Design: Offers higher efficiency, longer lifespan, and lower maintenance compared to brushed motors.

• High Precision: Excellent accuracy in controlling rotor rotation angle due to the high-resolution encoder feedback.

• High Efficiency: Converts electrical energy into mechanical power with minimal losses.

• Compact Size: Often designed to be compact for integration into various machinery.

• Dynamic Performance: Capable of rapid acceleration and deceleration, making it suitable for dynamic applications.

• Smooth Operation: AC servo motors, especially those controlled by sine waves, typically exhibit very low torque ripple, leading to smooth and quiet operation.

Product Parameters

Based on available information for the USAFED-30C220E:

• Motor Type: AC Servo Motor

• Rated Output Power: 2.9 kW (Kilowatts)

• Rated Current: 20 A (Amperes)

• Rated Torque: 18.6 Nm (Newton-meters)

• Rated Speed: 1500 RPM (Revolutions Per Minute)

• Instantaneous Max Speed: Often higher than rated speed (specific value may vary, but around 2000 RPM is common for similar models).

• Encoder: Typically paired with a high-resolution incremental encoder, such as UTOPH-81AWF (8192 Pulses/Revolution).

• Excitation: Permanent magnet.

• Insulation Resistance: 500 VDC, 10 MΩ or more.

• Enclosure: Totally-enclosed, self-cooled (Equivalent to IP-55 exclusive shaft opening)

• Ambient Temperature: 0 to +40°C

• Ambient Humidity: 20% to 80% (non-condensing)

• Vibration: 15 µm or below

• Finish (Munsell Notation): N1.5

Product Advantages

• Superior Control Performance: Achieves highly accurate control over position, speed, and torque, crucial for demanding automation tasks.

• High Reliability: Robust construction and Yaskawa's reputation for quality ensure long-term, dependable operation.

• Energy Efficiency: Optimizes power consumption through precise control, leading to reduced operating costs.

• Smooth and Quiet Operation: The sinusoidal control and brushless design minimize vibration and noise.

• Long Service Life: Absence of brushes reduces wear and tear, contributing to extended operational life and lower maintenance.

• Suitable for Dynamic Loads: Capable of handling rapid changes in speed and load, making it ideal for applications requiring quick movements.

Precautions

• Proper Sizing: Ensure the motor is correctly sized for the application's load, speed, and torque requirements to prevent damage and ensure optimal performance.

• Compatible Servo Amplifier: This motor must be paired with a compatible Yaskawa servo amplifier (drive) designed to work with this specific motor series and encoder type. Incorrect pairing can lead to malfunction or damage.

• Correct Wiring: Strictly adhere to the wiring diagrams provided by Yaskawa for power, encoder, and control signals. Improper wiring can cause damage to the motor or drive, or lead to unsafe operation.

• Grounding: Ensure proper grounding of both the motor and the servo amplifier to prevent electrical noise and ensure safety.

• Environmental Conditions: Operate the motor within its specified ambient temperature and humidity ranges. Avoid excessive dust, moisture, or corrosive environments unless the motor's enclosure rating specifically allows it.

• Mechanical Installation: Securely mount the motor to minimize vibration and ensure proper alignment with the driven load.

• Maintenance: Although brushless, regular checks of connections, bearings (if accessible), and ensuring proper cooling are recommended.

• Discontinuation: As this model might be discontinued, consider availability of spare parts and repair services. Plan for potential upgrades to newer Yaskawa servo systems for long-term support.

Product Applications

Yaskawa AC servo motors like the USAFED-30C220E are widely used in a variety of industrial automation and motion control applications that demand high precision and dynamic performance, including:

• Machine Tools: CNC machines, milling machines, lathes, grinding machines for precise axis control.

• Robotics: For articulated arms, grippers, and other robotic movements requiring high accuracy and repeatability.

• Packaging Machinery: Controlling precise movements for filling, sealing, cutting, and conveying.

• Printing Machinery: For accurate paper feeding, registration, and web tension control.

• Textile Machinery: Controlling winding, weaving, and spinning processes.

• Semiconductor Manufacturing Equipment: For highly precise wafer handling and positioning systems.

• Material Handling Systems: Automated storage and retrieval systems (AS/RS), gantry robots, and precise conveyor systems.

• Medical Equipment: In devices requiring precise and repeatable motion, such as diagnostic equipment or surgical robots.

• Food Processing Machinery: For precise mixing, cutting, and portioning.
