ABB 1TGE120021R0010 screwed ferrule terminal block

Product Detailed Description:

The ABB 1TGE120021R0010 is a type of terminal block used for electrical connections in industrial control panels and automation systems. Specifically, it is a screwed ferrule terminal block, which means it is designed to accept insulated conductor ends called ferrules.

These ferrules are crimped onto the stripped ends of wires (usually copper) to provide a clean, reliable, and corrosion-resistant termination point. The terminal block itself uses screws to secure the ferrule and wire into the block, ensuring a solid electrical connection.

This type of terminal block is part of ABB’s range of connection products, known for their reliability and ease of use in various industrial environments.

Product Parameters:

• Product Type: Screwed Ferrule Terminal Block

• Mounting: Panel Mount (typically DIN rail mountable)

• Conductor Material: Designed for copper conductors

• Connection Method: Screw termination for ferrules

• Ferrule Type: Accepts specific ferrule sizes (exact sizes depend on the specific block variant within this series, often indicated by additional codes or selection charts - common sizes might include 0.5 mm² to 6 mm² or similar, but verify the datasheet).

• Number of Poles/Positions: Typically one pole per block, but available in multi-pole versions (e.g., 2, 3, 4, 5 poles per unit - confirm specific variant).

• Rated Voltage: Usually 600 V AC / DC (verify datasheet)

• Rated Current: Typically 16 A or 32 A per pole (verify datasheet for the specific 1TGE variant)

• Degree of Protection (IP): Often IP2X or IP4X for the terminal block itself when mounted.

• Material: Housing typically made of high-quality thermoplastic (e.g., polycarbonate).

• Colour: Usually grey or black.

Product Advantages:

• Reliability: Provides a secure and stable electrical connection, reducing the risk of loose connections and associated issues like arcing or overheating.

• Corrosion Resistance: The use of ferrules protects the copper conductor from oxidation and corrosion, especially important in humid or contaminated environments.

• Ease of Assembly: Standardized crimping tools are used for ferrules, and screw terminals are straightforward to use. This speeds up installation compared to direct wire entry or soldering.

• Modularity & Flexibility: Terminal blocks can be easily added or removed, and are available in various pole counts and configurations, allowing for flexible panel design.

• Safety: Insulated design minimizes the risk of short circuits and accidental contact with live parts.

• Standardization: Part of a widely used and recognized product family, making it easy to source and replace.

Precautions / Notes:

• Use Ferrules: Always use the correct size ferrule crimped onto the wire end before inserting it into the terminal. Do not insert bare wire or improperly crimped wire.

• Correct Ferrule Size: Use the ferrule size appropriate for the wire cross-section. Using an incorrect size can lead to poor connections or damage to the terminal.

• Proper Crimping: Ensure ferrules are crimped correctly using the recommended tools. Poor crimps can lead to wire pull-out.

• Torque: Tighten the screws to the manufacturer’s specified torque. Over-tightening can damage the terminal or ferrule; under-tightening can lead to a loose connection.

• Wire Gauge Limits: Do not exceed the maximum and minimum wire gauge ratings for the specific terminal block variant.

• Environmental Conditions: Ensure the terminal block is suitable for the environmental conditions (temperature, humidity, vibration) of the installation location.

• Installation: Install according to local electrical codes and ABB’s installation instructions. Ensure proper grounding.

• Verify Specifications: Always double-check the exact specifications (current, voltage, wire size range) from the official ABB datasheet for the 1TGE120021R0010 before use.

Product Applications:

Screwed ferrule terminal blocks like the ABB 1TGE120021R0010 are fundamental components in a vast range of electrical and automation applications, including:

• Industrial Control Panels

• PLC (Programmable Logic Controller) Systems

• Motor Control Centers (MCCs)

• Distribution Boards

• Automation Machinery

• Packaging Equipment

• Conveyors and Material Handling Systems

• Building Management Systems (BMS)

• General Electrical Installations requiring reliable and organized wiring terminations.
