ABB 70BT01C Push button indicator unit

ABB 70BT01C Overview

The ABB 70BT01C is a Pushbutton with Indicator Unit. It belongs to ABB's modular range of pushbuttons and indicator lights, used in industrial control panels and Human Machine Interfaces (HMIs). This unit combines the functionality of a pushbutton for control input and an indicator light for status feedback to the operator.

Product Detailed Description

• Function:

• Pushbutton Function: Operators can press the button to start, stop, or control machines or processes.

• Indicator Light Function: The integrated indicator light can display the status of the machine or process (e.g., running, stopped, fault). The indicator light is typically controlled by an external signal.

• Features:

• Modular design for easy installation into standard 22.5 mm mounting holes.

• Robust industrial-grade design to withstand harsh environments.

• Wide range of colors and contact configurations available (although the specific contact configuration for this model needs to be checked in the datasheet).

• Indicator lights typically use LED light sources, offering long life and low power consumption.

• High front panel protection rating against dust and water ingress.

Product Parameters

As the ABB 70BT01C may have different configurations, the following are some general parameters for pushbutton with indicator units. Always refer to the official datasheet for the specific model for accurate parameters:

• Mounting Hole Size:

• 22.5 mm

• Pushbutton Type:

• Normally Open (NO), Normally Closed (NC), or both (depending on configuration).

• Momentary or maintained (depending on configuration).

• Contact Rating:

• Voltage and current ratings depend on the specific contact block (usually ordered separately or integrated with the button unit).

• Indicator Light Type:

• LED

• Indicator Light Color:

• May be available in red, green, yellow, blue, white, etc.

• Rated Voltage (Indicator Light):

• May be available in 24 V AC/DC, 110 V AC, 230 V AC, etc. (depending on the specific model).

• Protection Degree (IP):

• Front panel typically IP66 or higher.

• Wiring terminal area may have a lower protection rating.

• Operating Temperature:

• Typically -25 °C to +70 °C or similar range (depending on the specific model).

• Mechanical Life:

• Typically millions of operations.

• Electrical Life:

• Depends on the load and contact configuration.

Product Advantages

• Integrated Functionality:

• Combines control input and status indication in one unit, saving panel space and wiring.

• Modular Design:

• Easy to install and replace.

• Different contact blocks and indicator light colors can be selected as needed.

• Robust and Durable:

• Suitable for industrial environments with good resistance to shock and vibration.

• High Protection Degree:

• High front panel protection rating against dust and water ingress.

• High Reliability:

• ABB is a well-known manufacturer of industrial components with reliable product quality.

• Easy Identification:

• Wide range of colors allows operators to quickly identify functions and statuses.

Precautions

• Correct Selection:

• Choose the appropriate model and configuration based on specific control requirements (momentary/maintained, NO/NC contacts) and indication needs (color, voltage).

• Correct Installation:

• Follow ABB's installation guidelines, ensuring the pushbutton with indicator unit is securely mounted on the panel.

• Electrical Connection:

• Connect the button contacts and indicator light power lines correctly according to the wiring diagram.

• Ensure proper wiring and use appropriate wires and terminals.

• Contact Block Selection:

• Select the appropriate contact block (current and voltage ratings) based on the load requirements.

• Indicator Light Voltage Matching:

• Ensure the rated voltage of the indicator light matches the control signal voltage.

• Environmental Conditions:

• Avoid using the product in environments exceeding its operating temperature range.

• Regular Inspection:

• Regularly inspect the mechanical operation of the button and the working status of the indicator light.

Product Applications

ABB 70BT01C or similar pushbutton with indicator units are widely used in various industrial control and automation fields, such as:

• Industrial Control Panels:

• Machine start/stop control.

• Process control start/stop.

• Alarm indication.

• System status display.

• Human Machine Interfaces (HMIs):

• As control and indication elements for operator interaction with machines or processes.

• Distribution Boards:

• Equipment status indication.

• Special Machinery:

• Used for various custom control functions and status displays.

• Elevator and Crane Controls:

• Operation and status indication.
