ABB CI868 Communication interface module

ABB CI868 Overview

The ABB CI868 is a communication interface module for the ABB 800xA Distributed Control System (DCS). It primarily serves as a high-speed Ethernet interface for connecting controllers, I/O modules, and other 800xA system components, enabling real-time data exchange and communication.

Product Detailed Description

• Function:

• Provides a high-speed Ethernet communication interface for communication between internal components of the ABB 800xA system.

• Supports various Ethernet protocols, ensuring compatibility with other devices.

• Enables real-time data exchange between controllers, I/O modules, operator stations, engineering stations, etc.

• Supports redundant configurations to enhance system availability.

• Integrated network management functions for easy network diagnostics and maintenance.

• Features:

• High-speed Ethernet interface providing ample bandwidth.

• Supports various communication protocols such as TCP/IP, UDP, etc.

• Redundant Ethernet interface options for improved network reliability.

• Easy integration into the ABB 800xA system.

• LED indicators for status monitoring and troubleshooting.

• DIN rail mounting.

Product Parameters

As there may be different versions and configurations of the ABB CI868, the following are some typical parameters. Always refer to the official datasheet for the specific model:

• Interface Type:

• 1 or 2 x 10/100/1000 Mbit/s Ethernet ports (RJ45 connectors).

• Supported Protocols:

• TCP/IP, UDP, Ethernet, etc.

• Redundancy:

• Some models support Ethernet interface redundancy.

• Power Supply:

• 24 V DC (typical).

• Power Consumption:

• Varies by model.

• Degree of Protection:

• Typically IP20.

• Operating Temperature:

• Typically -40 °C to +70 °C (depending on the model).

• Mounting:

• DIN rail mounting.

• Dimensions (W x H x D):

• Varies by model.

• Weight:

• Varies by model.

Product Advantages

• High-Performance Communication:

• High-speed Ethernet interface provides ample bandwidth to meet real-time data exchange requirements.

• High Reliability:

• Supports redundant Ethernet interfaces, improving the reliability and availability of network communication.

• Easy Integration:

• Specifically designed for the ABB 800xA system, ensuring easy integration and configuration.

• Flexibility:

• Supports various Ethernet protocols, facilitating communication with other devices.

• Easy Maintenance:

• LED indicators facilitate status monitoring and troubleshooting.

Precautions

• Correct Installation:

• Follow ABB's installation guidelines, ensuring the module is securely mounted and properly connected.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Network Configuration:

• Configure Ethernet parameters correctly to ensure proper network communication.

• Cable Connections:

• Use appropriate Ethernet cables and ensure reliable connections.

• Redundancy Configuration:

• If redundancy is required, configure the redundant network correctly.

Product Applications

• ABB 800xA Distributed Control System (DCS):

• Connecting controllers, I/O modules, operator stations, engineering stations, etc.

• Building high-speed, reliable control networks.

• Enabling real-time data acquisition and control.

• Supporting large-scale industrial automation applications.
