ABB PFEA111-65 3BSE028140R0065 Tension Controller

Brand： ABB

Model number：AWT420 3KXA005011U0000

Warranty: 12 months

Lead Time：3-day working day

Country of origin: USA Price: Please contact us

Product weight：0.2kg

Shipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

ABB PFEA111-65 3BSE028140R0065 Tension Controller

INQUIRE NOW

Products Name: ABB PFEA111-65 3BSE028140R0065 Tension Controller

PRODUCT DESCRIPTION

The ABB PFEA111-65 is a high-performance, cost-effective Tension Electronics unit designed for industrial web tension measurement. It is part of the Tension Electronics PFEA series, specifically engineered to interface with ABB's PillowBlock and Radial tension load cells.

Product Specifications (Parameters)

Feature	Details
Product ID	3BSE028140R0065
Model Type	PFEA111-65 (IP65 Version)
Supply Voltage	24 V DC (18–35 V DC)
Protection Class	IP65 (Dust-tight and protected against water jets)
Input Channels	1 Channel (Supports 2 load cells in a single measuring zone)
Output Signal	0 to ±10 V / 0 to 20 mA / 4 to 20 mA (Configurable)
Display	Integrated 2-line LCD display with backlight
Communication	Profibus-DP (standard for this model)
Operating Temp	0 to +55 °C

Key Product Advantages

Exceptional Accuracy: Provides precise tension measurement even in harsh environments with significant vibrations.
Robust Protection: The IP65-rated enclosure allows the unit to be mounted directly on the machine in wet or dusty areas without an additional cabinet.
Ease of Commissioning: Features a user-friendly display and a "Quick Set-up" menu, allowing for calibration without needing external weights in many cases.
Built-in Diagnostics: Includes continuous self-monitoring and error detection to minimize downtime.
Compact Design: Small footprint makes it easy to integrate into existing control systems or mount on wall surfaces.

Product Application

The PFEA111-65 is primarily used in industries where web tension control is critical for product quality:

Paper & Pulp: Controlling the tension of paper webs during winding and slitting.
Converting: Used in laminating, coating, and printing processes.
Metals: Managing tension in steel or aluminum foil rolling and processing lines.
Textiles: Ensuring consistent tension for fabric processing.

Critical Considerations & Precautions

Wiring Integrity: Ensure that the load cell cables are shielded and separated from high-power cables to prevent electromagnetic interference (EMI).
Power Supply: Use a stabilized 24V DC power source. Voltage fluctuations outside the 18–35V range can lead to measurement errors or hardware damage.
Load Cell Matching: This unit is optimized for ABB's proprietary load cells (e.g., PFCL, PFTL series). Ensure compatibility before connecting third-party sensors.
Grounding: Proper earthing of the IP65 enclosure and the cable shields is mandatory to ensure signal stability.
