Product Description
The ABB TTH200-Y0 is a versatile head-mount temperature transmitter designed for a wide range of industrial applications. It combines a temperature sensor with HART communication, offering accurate
and reliable temperature measurement.
Key Features and Benefits
Universal Sensor Input: Accommodates various temperature sensors, including thermocouples, RTDs, and millivolt signals.
High Accuracy: Delivers precise temperature measurements with a typical accuracy of 0.1%.
HART Communication: Enables advanced configuration, diagnostics, and data management.
Robust Construction: Designed for harsh industrial environments, offering excellent resistance to vibration, shock, and corrosion.
Enhanced Diagnostics: Provides advanced diagnostic features, including sensor break detection, corrosion monitoring, and process variable limits.
Safety Certifications: Complies with various safety standards, such as ATEX, IECEx, FM, and CSA, for use in hazardous areas.
Technical Specifications
Input: Universal sensor input for RTDs, thermocouples, millivolt signals
Output: 4-20mA, HART
Accuracy: Typically 0.1%
Long-term Stability: 0.05%
Diagnostics: Sensor break, corrosion monitoring, process variable limits
Safety: ATEX, IECEx, FM, CSA
Communication: HART
Precautions
Sensor Selection: Choose the appropriate sensor based on the measurement range and process conditions.
Installation: Follow the manufacturer's guidelines for proper installation to ensure accurate measurements.
Calibration: Regular calibration is recommended to maintain accuracy.
Environmental Conditions: Avoid exposing the transmitter to excessive temperature, humidity, or vibration.
Applications
The TTH200-Y0 is suitable for a wide range of applications, including:
Process Industry: Temperature measurement in process plants, refineries, and chemical plants
Power Generation: Monitoring temperature in power plants and substations
Oil and Gas: Temperature measurement in pipelines and production facilities
Food and Beverage: Monitoring temperature in food processing and storage
HVAC: Temperature control in heating, ventilation, and air conditioning systems
