AF09-30-10 ABB Feeder Protection and Control

INQUIRE NOW

Products Name: AF09-30-10 ABB Feeder Protection and Control

PRODUCT DESCRIPTION

Brand:  ABB

Model number:AF09-30-10

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.4kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

The AI835/AI835A provides 8 differential input channels for

Thermocouple/mV measurements. Measurement ranges configurable

per channel are: -30 mV to +75 mV linear, or TC Types B, C, E, J, K, N, R,

S and T, for AI835A also D, L and U.

One of the channels (Channel 8) may be configured for “Cold

Junction” (ambient) temperature measurements, thus serving as CJchannel

for Ch. 1...7. The junction temperature may be measured

locally on the MTUs screw terminals, or on a connection unit distant

form the device.

Alternatively, a fix junction temperature for the module may be set by

the user (as parameter) or for AI835A also from the application.

Channel 8 may be used in the same manner as Ch. 1...7 when no CJtemperature

measurement is needed.

Features and benefits

8 differential input channels for thermocouple/mV.

Channel 8 can be designated as the CJ-channel (4-wire Pt100 RTD)

Variety of thermocouples with the following characteristics: B, C, E, J, K, N, R, S and T for AI835A also D,

L and U

15 Bit resolution (A/D)

Inputs are monitored for wire-break open-circuit

General info

Article number 3BSE051306R1

Type Analog Input

Signal specification -30..75 mV linear; TC types B, C, D, E, J, K, L, N, R, S, T and U

Number of channels 8

Signal type See table in S800 Modules and Termination Units, 3BSE020924

HART No

SOE No

Redundancy No

High integrity No

Intrinsic safety No

Mechanics S800

AI835A ABB   Feeder Protection and Control

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
