Mechanical Interlock
• For interlocking of two contactors
• Two fixing clips included
Mechanical only, without
auxiliary contacts
100-E09…100-E38 (3 pole),
100-E09Ä400…100-E38Ä400 100-EMCA00A(1)
(1) Must be ordered in multiples of 10 pieces.
100-E40…100-E96 (3 pole),
100-E40Ä400…100-E80Ä400 100-EMCA00B(1)
Mechanical Interlock
• For interlocking of two contactors.
• Interlocking of different sizes possible
Mechanical only, without
auxiliary contacts
100-E116...100-E146
100-EM1-00 100-E190...100-E205
100-E265...100-E370
100-E116...100-E146
to 100-E190...100-E205 100-EM4-00
100-E190...100-E205
to 100-E265...100-E370 100-EM5-00
100-E400…100-E750, 100-E1260 (2)
(2) Mounting plate ordered separately
100-EM2-00
100-E860…100-E1060,
100-E2050…100-E2650 (3)
(3) Mounting plate included
100-EM3-00
Rod for vertical mounting
100-E400…E750 reversing contactors 100-EVR750
Mechanical and Electrical Interlock
• For interlocking of two contactors
• Two fixing clips, a mechanical interlock
and an electrical interlock block with A2-
A2 connection included
• Front-face connection of the electrical
interlock block connects the 2 built-in
N.C. interlocking contacts with the
two coils
• The electrical diagram is used with the
A2-A2 connection
Mechanical/electrical
interlock
100-E09…100-E38 (3 pole),
100-E09Ä400…100-E38Ä400 100-EMCA02(4)
(4) Not for use with contactors that have EQ or QJ coils.
Electronic Timers
Description Connection
Diagrams For Use With Cat. No.
N.O. N.C.
Electronic Timing Module—ON-Delay
• Delay of the contactor coil
• The contactor is energized at the end of the delay time
ON-Delay
0.1…1 s
1…10 s
10…100 s
1 1 100-E09…100-E96,
24…240V AC/DC 100-ETA
Electronic Timing Module—OFF-Delay
• Delay of the contactor coil
• After interruption of the control signal, the contactor is
de-energized a the end of the delay time
OFF-Delay
0.1…1 s
1…10 s
10…100 s
1 1 100-E09…100-E96,
24…240V AC/DC 100-ETB
DC Interface Module
Description For Use With Pkg. Qty. Cat. No.
DC Interface
• Receives 24V DC signals from PLCs or other low output power sources and
switches AC control power to operate the coils of the contactor
• Coil voltage: 24…250V AC 50/60 Hz
• Rated control circuit voltage Uc: 24VDC
100-E09…100-E96
1 100-EJE
10 100-EJEM
