Brand： Allen Bradley
Model number：1761-CBl-AP00
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.21kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Observe the following safety precautions when troubleshooting your
Ultra3000 drive.
DC bus capacitors may retain hazardous voltages
after input power has been removed. Before
working on the drive, measure the DC bus voltage to
verify it has reached a safe level or wait the full time
interval listed on the drive warning label. Failure to
observe this precaution could result in severe bodily
injury or loss of life.
Do not attempt to defeat or override the drive fault
circuits. You must determine the cause of a fault and
correct it before you attempt to operate the system. If
you do not correct a drive or system malfunction, it
could result in personal injury and/or damage to the
equipment as a result of uncontrolled machine
system operation.
Test equipment (such as an oscilloscope or chart
recorder) must be properly grounded. Failure to
include an earth ground connection could result in a
potentially fatal voltage on the oscilloscope chassis.
This section provides information to assist you in wiring the Ultra3000
CN1 (44-pin) cable connector with either the ControlLogix
1756-M02AE servo module or SoftLogix™ 1784-PM02AE motion card.
Use the 2090-U3AE-D44xx control interface cable (shown below)
when connecting two Ultra3000 drives to the 1756-M02AE servo
module. This cable includes the 1756-TBCH pre-wired terminal block.
Refer to Figure B.22 for the interconnect diagram.
