A-B 1761-L16AWA Programmable Logic Controller

Product Description

The Allen-Bradley 1761-L16AWA is a compact and versatile MicroLogix 1000 controller designed for a wide range of industrial automation applications. This self-contained unit integrates a power supply, processor,

and I/O circuits into a single package, offering a cost-effective and efficient solution for various control tasks.

Key Features and Specifications

• I/O Configuration: 16 total I/O points, including 10 AC inputs and 6 relay outputs.



• Memory: 1K EEPROM user memory capable of storing up to 400 data words or more than 700 instruction words.



• Performance: Supports 40 timers and offers an average program scan time of 2 milliseconds and an average I/O scan time of 0.21 milliseconds.



• Physical Dimensions: 5.24 x 2.87 x 3.15 inches, weighing 1.40 pounds.



• Environmental: Operates in temperatures ranging from 32 to 131°F (horizontal mounting) and 32 to 104°F (vertical mounting).

• Safety: Features a master control relay for emergency shutdown and an IP20 enclosure.

• Communication: Supports various communication protocols for integration with other devices and systems.



Advantages

• Compact and Rugged: Its small size and durable construction make it suitable for space-constrained environments.

• Flexible I/O: The combination of AC inputs and relay outputs provides versatility for different applications.

• Easy Programming: User-friendly programming software simplifies configuration and control.

• Reliable Performance: Built with high-quality components to ensure long-term reliability.

• Cost-Effective: Offers a balance of performance and affordability.

Precautions

• Environment: Avoid exposure to excessive heat, moisture, or vibration.

• Power: Ensure proper power supply and grounding to prevent damage.

• Installation: Follow the manufacturer's guidelines for correct installation and wiring.

• Maintenance: Regularly inspect the controller for signs of wear or damage.

Applications

The 1761-L16AWA is well-suited for a wide range of applications, including:

• Machine control: Controlling simple machines and processes.

• Conveyor systems: Managing material handling and sorting operations.

• Packaging systems: Controlling packaging machines and processes.

• Data acquisition: Collecting and processing data from various sensors and devices.

Additional Information

For detailed information, including technical specifications, programming instructions, and troubleshooting guides, refer to the official Allen-Bradley documentation:

• Installation Instructions: 1761-IN001D-EN-P

• User Manual: 1761-UM003B-EN-P

Note: These documents can be found on the Rockwell Automation website.

In conclusion, the Allen-Bradley 1761-L16AWA is a reliable and versatile PLC controller that offers a cost-effective solution for various industrial automation applications. Its compact size, flexible I/O, and easy programming

make it a popular choice for engineers and technicians.
