A-B 1797-BIC BUS ISOLATOR MODULE FLEX EXTENDER

Product Description

The Allen-Bradley 1797-BIC is a Flex Ex Bus Isolator designed to isolate electrical signals on a communication bus. This isolation protects devices on one segment from electrical faults on another segment, enhancing

safety and reliability in industrial environments where electrical disturbances can occur.

Product Features

• Isolation: Provides electrical isolation between different segments of a FLEX Ex network.

• Safety: Enhances safety by preventing the propagation of electrical faults.

• Flexibility: Configurable for use in both safe and hazardous areas.

• Cost-effective: A cost-effective solution for combining intrinsically safe and non-intrinsically safe systems.

• Compact: Designed for DIN rail mounting.

Product Specifications

• Voltage: 18-32 VDC

• Current: 150 mA

• Power: 2.5 W

• Mounting: DIN rail

• Approvals: Meets European Hazardous Location Approval (for 1797-BIC)

Product Advantages

• Improved safety: Reduces the risk of electrical hazards.

• Increased system reliability: Protects devices from damage caused by electrical faults.

• Flexibility: Can be used in a variety of applications.

• Easy to install: DIN rail mounting for quick and easy installation.

Precautions

• Compatibility: Ensure compatibility with other FLEX Ex components.

• Installation: Follow the manufacturer's installation instructions carefully.

• Maintenance: Regular inspection and maintenance are recommended.

Applications

• Process automation: Used in hazardous areas where process control is required.

• Oil and gas: Ideal for applications in the oil and gas industry.

• Chemical processing: Suitable for use in chemical processing plants.

• Mining: Used in mining applications to improve safety and reliability.

Note: This information is intended for general reference only and should not be used as a substitute for professional engineering advice. Always consult the product documentation and applicable safety standards for

 specific application requirements.

Would you like to know more about a specific aspect of the 1797-BIC, such as its installation process, compatibility with other devices, or troubleshooting tips?
