AB 700-P400A1 Industrial Relay AC Operated

Product Overview

The Allen-Bradley 700-P400A1 is a heavy-duty industrial relay designed for a wide range of applications. It offers reliable performance, durability, and versatility, making it a popular choice in industrial automation.

Product Specifications

• Voltage: 110V 50Hz / 115-120V 60Hz

• Current: 10 Amp AC

• Contacts: 4 Normally Open (NO)

• Mounting: Open Type DIN Rail Mount

• Enclosure: NEMA

• Features: Standard and time delay contacts, electrical holding coil

Product Advantages

• Reliability: Built to withstand harsh industrial environments.

• Versatility: Suitable for various control applications.

• Durability: High-quality construction ensures long-lasting performance.

• Ease of Installation: DIN rail mounting for quick and easy installation.

• Compatibility: Compatible with other Allen-Bradley components.

Precautions

• Voltage Rating: Ensure the supply voltage matches the relay's specifications.

• Current Rating: Do not exceed the rated current to prevent damage.

• Mounting: Securely mount the relay to the DIN rail.

• Wiring: Follow proper wiring procedures to avoid electrical hazards.

• Environment: Protect the relay from excessive heat, moisture, and vibration.

Applications

• Motor Control: Starting, stopping, and reversing motors.

• Interlocking: Preventing unauthorized access to equipment.

• Timing: Creating time delays in control circuits.

• Sequencing: Controlling the order of operations in a process.

• Safety Circuits: Providing safety interlocks and emergency stop functions.

Additional Information

For more detailed information, including technical drawings, dimensional data, and ordering information, please refer to the official Allen-Bradley product data sheet or contact your local distributor.

[Insert link to the official product data sheet here]

Note: This is a general overview of the 700-P400A1. Specific applications and requirements may vary. Always consult the product documentation and seek expert advice if needed.
