A-B 140G-J6F3-D15 Programmable controller

Allen-Bradley 140G-J6F3-D15 Overview

The Allen-Bradley 140G-J6F3-D15 is a Molded Case Circuit Breaker (MCCB). It is primarily used to provide overcurrent and short-circuit protection for electrical circuits. As part of the 140G series, it is designed to offer reliable circuit protection with specific ratings and characteristics.

Product Detailed Description

• Function:

• Provides overcurrent protection to prevent damage to electrical equipment and wiring due to excessive current.

• Provides short-circuit protection to quickly interrupt the circuit in the event of severe electrical faults and reduce fire risk.

• Can be used as a manual switch for circuit energization and de-energization.

• Features:

• Thermal-magnetic trip unit: Combines thermal overload tripping (responds to sustained overcurrents) and magnetic short-circuit tripping (responds to rapid, high currents).

• Fixed mount.

• Three-pole (3-pole) configuration.

• May include an indicator to show the tripped status.

• Rugged industrial design.

Product Parameters

Due to the specific model number, the following are inferences based on the code and common parameters for the general 140G series. Always refer to the official datasheet for the specific 140G-J6F3-D15 model for accurate parameters:

• Frame Size:

• J Frame

• Number of Poles:

• 3-pole

• Trip Type:

• Thermal-Magnetic

• Rated Current (In):

• D15 likely indicates 15 Amperes (verify with official datasheet).

• Rated Operating Voltage (Ue):

• May be suitable for voltages up to 600V AC or higher (verify with official datasheet).

• Interrupting Capacity (Icu / Ics):

• Depends on the voltage rating; specific values should be checked in the datasheet. Icu is the ultimate short-circuit breaking capacity, and Ics is the service short-circuit breaking capacity.

• Mounting Style:

• Fixed Mount

• Standards Compliance:

• May comply with standards such as UL 489, CSA C22.2 No. 5 (verify with official datasheet).

• Ambient Temperature:

• Operating temperature range should be checked in the datasheet.

• Connection Method:

• Likely Bolt-on terminals.

Product Advantages

• Reliable Overcurrent and Short-Circuit Protection:

• Thermal-magnetic trip unit provides comprehensive circuit protection.

• Robust and Durable:

• Suitable for industrial environments.

• Easy to Install and Operate:

• Fixed mount simplifies the installation process.

• Can be used as a manual switch.

• Global Certifications:

• May comply with multiple international and regional standards.

Precautions

• Correct Selection:

• Choose the appropriate circuit breaker based on the circuit's rated current, expected fault current, voltage rating, and application requirements.

• Correct Installation:

• Follow Rockwell Automation's installation guidelines, ensuring the circuit breaker is securely mounted and correctly wired.

• Regular Inspection:

• Periodically inspect the circuit breaker for any signs of damage, overheating, or other abnormalities.

• Handling After Tripping:

• After the circuit breaker trips, identify and resolve the fault before resetting the breaker.

• Safe Operation:

• Always adhere to electrical safety procedures during installation, maintenance, or operation.

Product Applications

• Industrial Automation:

• Protection of motor control circuits, power distribution circuits, etc.

• Commercial Buildings:

• Protection of lighting circuits, receptacle circuits, etc.

• OEM Equipment:

• Integrated into various industrial equipment to provide circuit protection.

• Distribution Panels and Control Cabinets:

• Used as main circuit breakers or branch circuit breakers.
