A-B 1746-A13 Output module

A-B (Allen-Bradley) SLC 5/03 Processor (1746-A13) Overview

The A-B 1746-A13 is a processor module within the Allen-Bradley SLC 5/03 Programmable Logic Controller (PLC) family. The SLC 5/03 processor is a popular choice for small to medium-sized automation applications, offering real-time control, communication capabilities, and various memory options.

Product Detailed Description

• Function:

• Executes user-written control programs.

• Processes signals received from input modules.

• Controls signals sent to output modules.

• Provides communication interfaces to various industrial devices and networks.

• Manages the overall operation of the PLC system.

• Features:

• 16K words of user data memory.

• 4K words of user program memory.

• One RS-232/422/485 communication port supporting DF1 Full/Half Duplex, DF1 Radio Modem, DH-485, and ASCII protocols.

• Optional Ethernet communication via an additional module.

• Supports local I/O expansion (using 1746 series I/O modules).

• LED indicators for displaying processor status, operating mode, and communication activity.

• Requires installation in a 1746 series PLC chassis.

Product Parameters

• Processor Type:

• SLC 5/03

• User Data Memory:

• 16K words

• User Program Memory:

• 4K words

• Communication Ports:

• 1 x RS-232/422/485 port

• Supported Communication Protocols:

• DF1 Full/Half Duplex

• DF1 Radio Modem

• DH-485

• ASCII

• I/O Expansion:

• Supports local 1746 series I/O modules

• Power Requirements:

• Supplied by the PLC chassis power supply module

• Operating Temperature:

• 0 °C to +60 °C (refer to the official manual for specific details)

• Storage Temperature:

• -40 °C to +85 °C (refer to the official manual for specific details)

• Humidity:

• 5% to 95% non-condensing (refer to the official manual for specific details)

• Dimensions:

• Standard single-slot PLC module size

• Weight:

• Refer to the official manual

Product Advantages

• Mature and Reliable Technology:

• The SLC 5/03 series is a time-tested and reliable platform in industrial automation.

• Cost-Effective:

• Provides good performance and cost efficiency for small to medium-sized applications.

• Flexible Communication Options:

• Onboard RS-232/422/485 port supports several common industrial protocols.

• Easy Integration:

• Integrates well with Allen-Bradley's extensive range of I/O modules and software products.

• Large Installed Base:

• A significant number of existing applications and users across various industrial sectors.

• Easy Programming and Maintenance:

• Programmed using Rockwell Software's RSLogix 500 programming software, which is relatively easy to learn and use.

Precautions

• Correct Installation:

• Install the 1746-A13 processor module correctly into a compatible 1746 series PLC chassis.

• Power Requirements:

• Ensure the PLC chassis power supply module provides sufficient power for the processor and all connected I/O modules.

• Grounding:

• Ground the PLC system properly according to Allen-Bradley's grounding guidelines to prevent electrical noise.

• Programming Software:

• Rockwell Software's RSLogix 500 programming software is required to write, download, and monitor control programs.

• Communication Configuration:

• Configure the communication parameters (e.g., baud rate, data bits, parity, stop bits) of the RS-232/422/485 port correctly to match the connected devices.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the processor's specifications.

• Firmware Version:

• Be aware of the processor's firmware version and update it if necessary for the latest features and fixes.

Product Applications

• Small to Medium-Sized Automation Control:

• Suitable for applications that do not require extremely high performance and large memory capacity.

• Discrete Control:

• Controlling the starting, stopping, movement, and sequencing of machinery.

• Process Control:

• Can be used for some basic temperature, pressure, and flow control applications.

• Material Handling:

• Controlling conveyors, sorting systems, and robots.

• Packaging Machinery:

• Controlling filling machines, labeling machines, and sealing machines.

• Human-Machine Interface (HMI):

• Connecting to operator interfaces via the serial communication port.

• Data Acquisition:

• Can be configured to collect and transmit process data.
