A-B 2090-K6CK Low-Profile Connector Kit

1. Product Description

The 2090-K6CK is a Low-Profile Feedback Connector Kit. Its primary purpose is to provide a compact, reliable interface for feedback signals (like encoders) and I/O connections. It essentially converts the high-density connection on the front of the Kinetix drive into a more manageable terminal block or specialized connector format, allowing for easier wiring in tight cabinet spaces.

2. Technical Specifications

While specific dimensions vary slightly by version (e.g., 2090-K6CK-D15M or D15F), the general parameters include:

3. Product Advantages

• Space Efficiency: The "low-profile" design reduces the depth required in the electrical cabinet, which is vital for compact machine builds.

• Easy Maintenance: Features quick-connect terminals that allow for faster troubleshooting and replacement compared to traditional soldering or crimping.

• Signal Integrity: Built with high-quality shielding to minimize electromagnetic interference (EMI), ensuring stable feedback from the motor to the drive.

• Simplified Installation: Reduces the complexity of wiring high-density pins by breaking them out into clearly labeled terminal points.

4. Important Considerations (Precautions)

• Compatibility Check: Ensure the specific suffix (e.g., -D15M) matches your drive's feedback port. Using the wrong connector can lead to bent pins or communication errors.

• Shielding: To maintain EMC compliance, the cable shield must be properly grounded to the connector shell.

• Tightening Torque: If using screw-terminal versions, do not over-tighten, as this can damage the internal PCB of the connector.

• Environment: Ensure the connector is protected from conductive dust and moisture, as it is generally rated for IP20 environments (inside a cabinet).

5. Product Applications

The 2090-K6CK is widely used in high-performance motion control environments, including:

• Packaging Machinery: Coordinating multiple axes for high-speed wrapping and labeling.

• Automotive Assembly: Robotic arms and precision positioning stages.

• Material Handling: Automated storage and retrieval systems (ASRS).

• Printing and Converting: Maintaining tension and registration control across long web lines.
