A-B Insulated Gate Bipolar Transistor (IGBT) Overview

Allen-Bradley (part of Rockwell Automation) does not directly manufacture semiconductor devices like IGBTs. IGBTs are typically products of power electronics manufacturers (such as Infineon, Fuji Electric, Mitsubishi Electric, etc.) and are then integrated into various industrial automation equipment from Allen-Bradley, such as AC drives, servo drives, and power supplies.

Therefore, the following information provides a general overview of IGBTs from the perspective of their use within Allen-Bradley equipment, their role, and advantages in A-B products.

Product Detailed Description (General IGBT Information in A-B Products)

• Function:

• In Allen-Bradley's power electronic devices, IGBTs serve as core switching elements to control the flow of current.

• In AC drives, IGBTs use high-speed switching to convert DC voltage into variable frequency and amplitude AC voltage, thereby controlling motor speed and torque.

• In servo drives, IGBTs are used to precisely control motor current and voltage, enabling high-precision position and speed control.

• In power supplies, IGBTs are used for efficient voltage conversion and regulation.

• Features (General IGBT Characteristics):

• Combines the easy gate drive characteristics of MOSFETs with the high current carrying capability of bipolar transistors.

• Exhibits high switching speeds, suitable for high-frequency applications.

• Low on-state losses, improving energy efficiency.

• Easily controlled by voltage signals.

• Robust and durable, suitable for industrial environments.

Product Parameters (General IGBT Parameters - May Vary Significantly by Specific Device)

Due to the vast number of IGBT models and parameters, the following lists only some common key parameters. Specific values depend on the particular IGBT device used in Allen-Bradley equipment:

• Collector-Emitter Voltage (Vce):

• The maximum voltage the IGBT can withstand.

• Collector Current (Ic):

• The maximum current the IGBT can carry.

• Gate-Emitter Voltage (Vge):

• The gate voltage range required to drive the IGBT.

• Switching Frequency (fsw):

• The maximum frequency at which the IGBT can switch reliably.

• On-State Resistance (Rce(on)):

• The equivalent resistance of the IGBT when turned on, affecting conduction losses.

• Rise/Fall Time (tr/tf):

• The time required for the IGBT to switch from off to on or from on to off, affecting switching losses.

• Package Type:

• TO-247, TO-220, IGBT modules, etc.

• Operating Junction Temperature (Tj):

• The maximum permissible operating temperature of the IGBT chip.

Product Advantages (Advantages of Using IGBTs in A-B Products)

• Efficient Energy Conversion:

• Low on-state losses and optimized switching characteristics contribute to higher overall energy efficiency of the equipment, reducing operating costs.

• Precise Motor Control:

• High switching capability and controllability enable Allen-Bradley's AC drives and servo drives to achieve precise motor speed and torque control, improving production efficiency and product quality.

• Compact Equipment Design:

• The high power density of IGBTs allows for more compact designs of drives and power supplies.

• High Reliability:

• Industrial-grade IGBT devices typically exhibit high reliability and durability, suitable for harsh industrial environments.

• Easy Control and Interfacing:

• The voltage-driven characteristics of IGBTs simplify the design of control circuits and interfacing with microcontrollers.

Precautions (General Precautions for IGBTs in A-B Products)

• Overvoltage Protection:

• Ensure proper overvoltage protection measures are in place to prevent damage to the IGBTs from voltage spikes.

• Overcurrent Protection:

• Implement reliable overcurrent protection mechanisms to prevent IGBT failure due to excessive current.

• Thermal Management:

• Provide effective heat dissipation solutions (such as heat sinks, fans) to ensure IGBTs operate within their permissible temperature range.

• Gate Drive:

• Use appropriate gate drive circuits that provide the correct voltage and current to ensure reliable switching of the IGBTs.

• ESD Protection:

• Observe electrostatic discharge (ESD) precautions when handling and maintaining Allen-Bradley equipment containing IGBTs.

• Follow Equipment Manuals:

• Always adhere to the installation, operation, and maintenance guidelines provided in the manuals for the relevant Allen-Bradley equipment.

Product Applications (Applications of IGBTs in A-B Products)

IGBTs are a crucial component in various industrial automation products from Allen-Bradley, including but not limited to:

• AC Drives:

• PowerFlex series drives used for controlling the speed of various industrial motors.

• Servo Drives:

• Kinetix series servo drives used for high-precision motion control applications.

• Power Supplies:

• Used to provide stable and reliable DC power for automation systems.

• Soft Starters:

• SMC series soft starters used for smooth starting and stopping of AC motors, reducing mechanical shock and current surges.

• Welding Equipment:

• Used to control welding current and voltage.
