A-B TLY-A230T-HK62AA Programmable controller

A-B (Allen-Bradley) TLY-A230T-HK62AA Overview

The A-B TLY-A230T-HK62AA is an industrial touchscreen Human Machine Interface (HMI) device belonging to the Allen-Bradley (Rockwell Automation) PanelView family. It is designed to provide an operator interface for industrial automation applications, used for monitoring and controlling machines and processes.

Product Detailed Description

• Function:

• Visualizes machine and process data.

• Allows operators to interact via the touchscreen to control equipment and adjust parameters.

• Communicates with PLCs (Programmable Logic Controllers) and other automation devices via various communication protocols.

• Supports features such as graphic displays, alarm management, trend displays, recipe management, and user management (specific features depend on the model and firmware).

• Features:

• Color touchscreen display providing an intuitive operator interface.

• Rugged industrial design suitable for harsh industrial environments.

• Supports multiple communication protocols for easy integration into existing control systems.

• May have interfaces such as Ethernet, serial (e.g., RS-232), and USB.

• Engineered and configured using Rockwell Automation's FactoryTalk View ME software.

Product Parameters

As the specific model suffix (e.g., -HK62AA) may indicate particular configurations, the following are some typical parameters for Allen-Bradley PanelView touchscreen HMIs. Always refer to the official datasheet for the specific model for accurate parameters:

• Display Size:

• May be 7 inches, 10 inches, 12 inches, or other sizes (depending on the series and model).

• Resolution:

• E.g., 800 x 600 pixels (SVGA) or higher.

• Touchscreen Type:

• Analog resistive touchscreen.

• Power Supply:

• Typically 24 V DC.

• Communication Interfaces:

• Ethernet port (may support EtherNet/IP).

• Serial port (e.g., RS-232).

• USB port (for connecting external devices or transferring programs).

• Memory:

• Internal memory for applications and data.

• Ingress Protection (IP) Rating:

• Front typically has a higher IP rating (e.g., IP65), rear may be lower.

• Operating Temperature:

• Typically in the range of 0 °C to +50 °C or similar.

• Certifications:

• CE, UL, cUL, etc. (refer to the specific product manual).

Product Advantages

• Reliability:

• Designed for industrial environments with high reliability and durability.

• Ease of Use:

• Intuitive touchscreen interface for easy operator monitoring and control.

• Integration with Rockwell Systems:

• Seamless integration with Allen-Bradley PLCs and other Rockwell Automation products.

• Powerful Functionality:

• Supports various visualization and control features to meet different application needs.

• Extensive Connectivity:

• Supports multiple industrial communication protocols.

• Global Support:

• Rockwell Automation provides extensive technical support and after-sales service worldwide.

Precautions

• Correct Installation:

• Follow Rockwell Automation's installation guidelines, ensuring the panel is securely mounted and properly grounded.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Engineering Software:

• Requires Rockwell Automation's FactoryTalk View ME software for application development and configuration.

• Cable Connections:

• Use appropriate cables to connect the HMI panel to PLCs and other devices, and ensure reliable connections.

• ESD Protection:

• Observe electrostatic discharge (ESD) precautions when handling the HMI panel.

Product Applications

The A-B TLY-A230T-HK62AA or similar Allen-Bradley PanelView HMI devices are widely used in various industrial automation fields, including but not limited to:

• Factory Automation:

• Machine control interfaces.

• Production line monitoring.

• Data acquisition and trend displays.

• Process Automation:

• Monitoring and control of process parameters.

• Alarm management.

• Packaging Machinery:

• Operator interface for setting up and monitoring packaging processes.

• Food and Beverage Industry:

• Control and monitoring of production equipment.

• Automotive Industry:

• Operator interface for robots and automated assembly lines.

• Water/Wastewater Treatment:

• Monitoring and control of water treatment processes.
