AB 1756-OB16D Digital Output Module

Product Description

The Allen Bradley 1756-OB16D is a ControlLogix DC diagnostic output module. It provides 16 discrete output points, each capable of sinking up to 500 mA. This module is commonly used in industrial automation applications to control various devices such as relays, solenoids, and other electrical loads.

Key Features and Benefits

• 16 discrete outputs: Provides ample output points for controlling multiple devices.

• Diagnostic capabilities: Built-in diagnostics help to quickly identify and troubleshoot issues.

• Compact design: Saves valuable space in the control panel.

• Rugged construction: Designed to withstand harsh industrial environments.

• Easy to configure: Integrates seamlessly into the ControlLogix system.

Technical Specifications

• Number of outputs: 16

• Output type: Sink

• Output current: 500 mA per point

• Supply voltage: 19.2 to 30 VDC

• Mounting: DIN rail

• Environmental: Industrial

Precautions

• Overload protection: Ensure that the connected load does not exceed the module's current rating.

• Wiring: Follow the manufacturer's wiring instructions carefully.

• Grounding: Proper grounding is essential for safe operation.

• Compatibility: Verify compatibility with other components in the system.

Applications

The 1756-OB16D module is suitable for a wide range of applications, including:

• Machine control: Controlling actuators, valves, and other devices in industrial machinery.

• Process control: Monitoring and controlling process variables.

• Packaging: Controlling conveyors, filling machines, and labeling systems.

• Material handling: Controlling robotic arms, cranes, and other material handling equipment.

Additional Information

• Short trip diagnostic: The module has a short trip diagnostic function for added safety.

• Keying: Electronic, software configurable.

• RTB keying: User-defined mechanical.

For more detailed information, please refer to the official product documentation.
