AB 1756-TIME Clock module

Rockwell Automation Allen-Bradley 1756-TIME Overview

The Allen-Bradley 1756-TIME module is a high-accuracy clock module for the ControlLogix control system. It provides precise timestamping capabilities for the ControlLogix controller, which is crucial for applications requiring accurate time synchronization and event logging.

Product Detailed Description

• Function:

• Provides high-accuracy timestamps for the ControlLogix controller.

• Allows the controller to precisely time-tag events with microsecond-level accuracy.

• Supports time synchronization over networks (e.g., EtherNet/IP).

• Can be configured as a time server or a time client.

• Offers battery backup to maintain time during power outages.

• Features:

• High-accuracy timestamping.

• Supports network time protocols (e.g., NTP, SNTP).

• Configurable as a time server or client.

• Battery backup.

• ControlLogix chassis-based module for easy integration.

Product Parameters

As there are different models and revisions within the 1756 series, the following are some general parameters. Always refer to the official datasheet for the specific model:

• Module Type:

• High-accuracy clock module.

• ControlLogix Chassis Compatibility:

• Compatible with ControlLogix chassis.

• Timestamp Accuracy:

• Typically in the microsecond range.

• Time Synchronization Protocols:

• Supports NTP, SNTP, etc.

• Network Interface:

• Typically communicates over the ControlLogix backplane for network time synchronization.

• Battery Backup:

• Provides a battery to maintain time.

• Current Draw:

• Varies by specific model.

• Operating Temperature:

• Varies by specific model.

Product Advantages

• High-Accuracy Timestamping:

• Provides precise time information for applications requiring accurate time recording and synchronization.

• Network Time Synchronization:

• Easily synchronizes time with other devices over a network.

• Reliability:

• As part of the ControlLogix system, it offers high reliability.

• Easy Integration:

• ControlLogix chassis-based module for easy installation and configuration.

• Battery Backup:

• Ensures that time is not lost during power outages.

Precautions

• Correct Installation:

• Install the module correctly into the ControlLogix chassis according to Rockwell Automation's installation guidelines.

• Power Requirements:

• Ensure the ControlLogix chassis provides sufficient power to the module.

• Network Configuration:

• If network time synchronization is required, configure the network parameters correctly.

• Battery Maintenance:

• Periodically check the battery status and replace it when necessary to ensure time is maintained during power outages.

• Software Configuration:

• Configure the module parameters correctly within the Rockwell Software Studio 5000 environment.

Product Applications

• Sequence of Events (SOE) Recording:

• Provides precise timestamps for troubleshooting and event analysis.

• Synchronized Control:

• Enables coordinated control of multiple devices or processes requiring accurate time synchronization.

• Data Logging and Analysis:

• Provides accurate timestamps for process data, facilitating subsequent analysis.

• Network Time Server:

• Can act as a time server within the control system, providing time synchronization to other devices.

• Regulatory Compliance:

• Meets regulatory requirements for precise timestamp recording in certain industries.
