Products Name: AB 1771-WN Multifunctional field wiring arm
PRODUCT DESCRIPTION
Product Description
The Allen-Bradley 1771-WN is a versatile field wiring arm designed for use with Allen-Bradley PLC-5 I/O modules.This component acts as a terminal strip, providing a convenient and flexible way to connect field devices to the I/O modules. The 1771-WN allows for easy wiring, maintenance, and module replacement without the need to disconnect field wiring.
Key Features and Specifications
32-point capacity: Provides up to 32 terminal points for connecting field devices.
40 terminals: Offers ample connection points for a variety of devices.
Pivot design: The arm pivots on the I/O chassis to connect with terminals on the front of the module.
Terminal strip: Acts as a terminal strip, providing a convenient way to connect field wiring.
Compatibility:Specifically designed for use with Allen-Bradley PLC-5 I/O modules.
Agency certifications: CSA certified, CSA Class I, Division 2 Groups A, B, C, D certified, UL listed, and CE marked.
Advantages
Flexibility: The pivot design allows for easy removal and replacement of modules without disconnecting field wiring.
Convenience: The terminal strip simplifies wiring and maintenance.
Reliability: Constructed with high-quality materials to ensure long-term performance.
Compatibility: Seamlessly integrates with Allen-Bradley PLC-5 systems.
Precautions
Wiring: Ensure proper wiring to prevent damage to the module and system.
Torque: Tighten the wiring arm screws to the specified torque to ensure a secure connection.
Static discharge: Handle the wiring arm with care to avoid electrostatic discharge, which can damage the module.
Power: Always remove power from the I/O chassis and wiring arm before making any connections.
Applications
Industrial automation: Used in a wide range of industrial applications, including manufacturing, packaging, and process control.
PLC systems: Provides a convenient way to connect field devices to Allen-Bradley PLC-5 systems.
I/O expansion: Can be used to expand the input/output capabilities of a PLC system.
Additional Information
Replacement: The 1771-WN is entirely configurable with the 1771-WH Wiring Arm, which can act as a direct replacement.
Conversion: The input/output Conversion System provides a quick and efficient way of converting 1771 PLC-5 to 1756 ControlLogix.
Fuses: When replacing fuses, ensure each fuse holder is removed without damaging or changing the output module.
Static discharge: The 1771-WN output contact is highly sensitive to electrostatic discharge, so follow the provided guidelines to avoid damage.
By understanding the key features, advantages, and precautions associated with the Allen-Bradley 1771-WN, you can effectively use this component in your PLC-5 system. For more detailed information, refer to the official Allen-Bradley documentation.
