AB 193-ED1EB Overload Relay

Product Description

The Allen Bradley 193-ED1EB is a solid-state overload relay designed to protect three-phase motors from overcurrent conditions. It's part of the Bulletin 193 E1 Plus series and is known for its reliability and versatility.

Key Features and Specifications

• Trip Class: 10 (trips in 10 seconds or less)

• Current Range: 5.4 to 27 amps

• Voltage Rating: 600V AC

• Reset: Manual

• Mounting: Directly mounts to Allen Bradley size 100-C09, 100-C12, 100-C16, or 100-C23 three-pole contactors

• Protection: Phase loss, ground fault

• Additional Features: Trip indication, reset and stop buttons

Advantages

• Adjustable Trip Class: Provides flexibility to match different motor protection requirements.

• Manual and Automatic Reset: Allows for both manual and automatic restart of the motor.

• Compact Design: Easy to install and fits in tight spaces.

• Reliable Performance: Ensures long-term protection of your equipment.

• Wide Range of Applications: Suitable for a variety of industrial applications.

Precautions

• Proper Wiring: Ensure correct wiring of the overload relay to prevent damage and incorrect operation.

• Ambient Temperature: Operate within the specified temperature range to maintain optimal performance.

• Overload Current: Do not exceed the rated overload current to avoid damage to the relay.

• Grounding: Proper grounding is essential for safe operation.

Applications

• Motor Protection: Protects three-phase motors from overload, phase loss, and ground faults.

• Industrial Automation: Used in various industrial applications such as conveyor systems, pumps, and fans.

• OEM Equipment: Incorporated into original equipment manufacturer (OEM) machinery.

Summary

The Allen Bradley 193-ED1EB overload relay is a robust and reliable solution for protecting three-phase motors. Its adjustable trip class, compact design, and versatile features make it a popular choice for a wide range of applications. By following the recommended precautions, this relay can provide years of dependable service.
