AB 22B-D6PON104 AC Drive

AB PowerFlex 40 AC Drive Overview

The AB PowerFlex 40 is a cost-effective and easy-to-use AC drive designed for controlling the speed of three-phase induction motors in a variety of industrial applications. Model 22B-D6PON104 represents a specific configuration within this series.

Product Detailed Description

• Function:

• Controls the speed and torque of three-phase AC induction motors.

• Provides motor starting, stopping, acceleration, and deceleration control.

• Features scalar control (V/f) mode.

• Offers basic overload and short-circuit protection for the motor.

• Integrated PID control for closed-loop process control.

• Provides basic digital and analog input/output interfaces for control and feedback.

• Features:

• Compact design to save installation space.

• Easy to install and wire.

• User-friendly interface and simple programming.

• Built-in EMC filter to meet CE standards.

• Supports various mounting options.

Product Parameters

The following are typical parameters based on model 22B-D6PON104. Always refer to the official Rockwell Automation datasheet for this specific model for the most accurate information:

• Power Rating:

• 4 kW (5 hp)

• Rated Voltage:

• 380-480V AC, 3-phase

• Rated Current:

• 6.0 A

• Output Frequency Range:

• 0-400 Hz

• Control Method:

• Scalar control (V/f)

• Input Voltage Range:

• 323-528V AC

• Input Frequency Range:

• 47-63 Hz

• Overload Capacity:

• 150% of rated current for 60 seconds

• Protection Rating:

• IP20 (Open Type)

• Ambient Temperature:

• -10 °C to +50 °C (14 °F to 122 °F)

• Digital Inputs:

• 5

• Analog Inputs:

• 1 (voltage or current selectable)

• Digital Outputs:

• 1 (programmable)

• Analog Outputs:

• 1 (current)

• Communication Interface:

• No built-in communication interface (typically requires optional modules)

• Braking:

• Built-in braking transistor (requires external braking resistor)

• EMC Filter:

• Built-in C2 EMC filter

Product Advantages

• Cost-Effective:

• Provides basic speed control functionality at a competitive price.

• Ease of Use:

• Simple installation, wiring, and programming.

• User-friendly LCD human-machine interface.

• Compact Design:

• Saves control cabinet space.

• Reliability:

• Backed by the Rockwell Automation brand.

• Built-in EMC Filter:

• Reduces electromagnetic interference, simplifying installation.

• Built-in Braking Transistor:

• Facilitates dynamic braking (requires an external resistor).

Precautions

• Correct Selection:

• Choose the appropriate model based on motor power, load characteristics, and application requirements.

• Correct Installation:

• Follow Rockwell Automation's installation guidelines, ensuring the drive is installed in a well-ventilated area with suitable ambient temperature.

• Correct Wiring:

• Connect the power supply, motor, and control signal lines correctly according to the wiring diagram, ensuring proper grounding.

• Parameter Settings:

• Set the drive parameters correctly according to the specific motor and application requirements.

• Overload Protection:

• While internal overload protection is provided, additional motor protection devices may be necessary in some applications.

• Braking Resistor:

• If frequent or high-power braking is required, an appropriate external braking resistor must be connected.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range, and avoid dust, corrosive gases, etc.

Product Applications

The AB PowerFlex 40 AC drive is suitable for a variety of industrial applications, especially those that do not require advanced control features and complex communication:

• Conveyors: Speed control.

• Fans and Pumps: Simple flow/pressure control.

• Packaging Machinery: Basic speed control.

• Material Handling Equipment: Simple motor control.

• Food and Beverage Industry: Certain applications.

• HVAC (Heating, Ventilation, and Air Conditioning): Fan and pump control.
