X20CS1020 B&R

X20 CPU, ATOM 333 MHz compatible, 128 MB DDR2 RAM, 1 MB SRAM, removable application

 memory: CompactFlash, 1 insert slot for X20 interface modules, 2 USB ports, 1 RS232 interface,

 1 Ethernet interface 10/100/1000 Base-T, 1 POWERLINK interface, incl. supply module,

X20TB12 terminal block and slot covers, X20 locking plate X20AC0SR1 (right) included, order

application memory separately.

1 General information

Based on state-of-the-art Intel® ATOM™ processor technology, the X20 CPUs cover a wide spectrum of demands.

They can be implemented in solutions ranging from standard applications to those requiring the highest levels of

performance.

The series starts with Intel® ATOM™ processor 333 MHz compatible models – X20CP1583 and X20CP3583. With

an optimum price/performance ratio, it has the same basic features as all of the larger CPUs.

The basic model includes USB, Ethernet, POWERLINK V1/V2 and removable CompactFlash. The standard Ethernet

 interface is capable of handling communication in the gigabit range. For improved real-time network performance,

 the onboard POWERLINK interface supports poll response chaining mode (PRC).

In addition, there are up to three multi-purpose slots for additional interface modules.

• Intel® ATOM™ 1600/1000/600 Performance with integrated I/O processor

• Entry-level CPU is Intel® ATOM™ 333 MHz-compatible with integrated I/O processor

• Ethernet, POWERLINK V1/V2 with poll response chaining and onboard USB

• 1 or 3 slots for modular interface expansion

• CompactFlash as removable application memory

• Up to 512 MB DDR2-SRAM according to performance requirements

• CPU redundancy possible

• Fanless

• Extremely compact

1) The specified values are maximum values. The exact calculation is included as a data sheet in the module documentation and can be downloaded from

the B&R website.

2) When operated at temperatures above 55°C, a derating of the rated output current to 5 W for the X2X Link supply must be taken into consideration.

3) In parallel operation, only 75% of the rated power can be assumed. It is important to make sure that all power supplies operating in parallel are switched

on and off at the same time.

4) Can be configured in Automation Studio.

5) 1 MB SRAM minus the configured remanent variables.

6) See the POWERLINK online help documentation under "General information, Hardware - IF/LS".
